Name: AYF332565A
Brand: Panasonic Electric Works
SKU: AYF332565A
Availability: InStock

new-10%

AYF332565A

Manufacturer part number:AYF332565A

Manufacturer:Panasonic Electric Works

Description:AYF332565A datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Panasonic Electric Works stock available on our website

Case Package:SOT-23

Datasheet:AYF332565A Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	8 Weeks
Contact Material	Copper Alloy
Contact Plating	Gold
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Housing Material	Liquid Crystal Polymer (LCP)
Actuator Material	Liquid Crystal Polymer (LCP)
Operating Temperature	-55°C~85°C
Packaging	Strip
Published	2008
Series	Y3BW
Part Status	Not For New Designs
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Number of Positions	25
Max Operating Temperature	85°C
Min Operating Temperature	-55°C
Voltage - Rated	50V
Current Rating (Amps)	0.2A per Contact
Pitch	0.012 0.30mm
Current Rating	200mA
Contact Finish	Gold
Mating Cycles	20
Flat Flex Type	FPC
Connector/Contact Type	Contacts, Top and Bottom
Cable End Type	Tabbed
Locking Feature	Rotary Lock, Backlock
Contact Finish Thickness	Flash
Height Above Board	0.035 0.88mm
FFC, FCB Thickness	0.20mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

AYF332565A Product Details

AYF332565A Overview

This device has a mounting type of Surface Mount, Right Angle.To package the product, a Strip case is used.The product belongs to the Y3BW Series.A temperature below 85°C is best for using it.Temperature must be -55°C to operate this device.You've got Surface Mount mounted on the part.In this case, the device operates at -55°C~85°C Operating Temperature.
