Name: 5019123590
Brand: Molex
SKU: 5019123590
Availability: InStock

new-10%

5019123590

Manufacturer part number:5019123590

Manufacturer:Molex

Description:5019123590 datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:5019123590 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	15 Weeks
Contact Material	Copper Alloy
Mounting Type	Surface Mount, Right Angle
Material	Thermoplastic
Housing Material	Polymer, Glass Filled
Actuator Material	Polymer, Glass Filled
Operating Temperature	-20°C~85°C
Packaging	Tape & Reel (TR)
Published	2016
Series	Easy-On 501912
JESD-609 Code	e4
Feature	Solder Retention
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Number of Positions	35
Number of Rows	1
Gender	Receptacle
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	0.2A
Pitch	0.012 0.30mm
Orientation	Right Angle
Depth	3.85mm
Current Rating	200mA
Contact Finish	Gold
Number of Contacts	35
UL Flammability Code	94V-0
Housing Color	Black
Contact Resistance	80mOhm
ELV	Compliant
Max Voltage Rating (AC)	50V
Wire/Cable Type	Straight
Mating Cycles	20
Flat Flex Type	FPC
Connector/Contact Type	Contacts, Bottom
Cable End Type	Tapered
Locking Feature	Flip Lock
Stackable	No
Contact Location	Bottom
Length	12.6mm
FFC, FCB Thickness	0.20mm
Material Flammability Rating	UL94 V-0
REACH SVHC	Unknown
RoHS Status	ROHS3 Compliant
Flammability Rating	UL94 V-0

5019123590 Product Details

5019123590 Overview

This device has a mounting type of Surface Mount, Right Angle.An Tape & Reel (TR) case is utilized for packaging the product.Specifically, it is one of the products in the Easy-On 501912 Series.This feature makes it more powerful in a number of ways due to its Solder Retention feature.Devices operate at -20°C~85°C operating temperatures.
