Name: FH19SC-9S-0.5SH(05)
Brand: Hirose Electric Co Ltd
SKU: FH19SC-9S-0.5SH(05)
Availability: InStock

new-10%

FH19SC-9S-0.5SH(05)

Manufacturer part number:FH19SC-9S-0.5SH(05)

Manufacturer:Hirose Electric Co Ltd

Description:FH19SC-9S-0.5SH(05) datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Hirose Electric Co Ltd stock available on our website

Case Package:SOT-23

Datasheet:FH19SC-9S-0.5SH(05) Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Phosphor Bronze
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Housing Material	Liquid Crystal Polymer (LCP)
Actuator Material	Liquid Crystal Polymer (LCP), Polyphenylene Sulfide (PPS)
Operating Temperature	-55°C~85°C
Packaging	Tape & Reel (TR)
Series	FH19SC
Feature	Solder Retention, Zero Insertion Force (ZIF)
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	FFC/FPC CONNECTOR
Number of Positions	9
Number of Rows	1
Voltage - Rated	50V
Subcategory	Headers and Edge Type Connectors
Current Rating (Amps)	0.5A
Pitch	0.020 0.50mm
Total Number of Contacts	9
Orientation	Right Angle
Current Rating	500mA
Reference Standard	UL
Contact Finish	Gold
Reliability	COMMERCIAL
Body Length or Diameter	0.256 inch
Number Of PCB Rows	1
Lead Pitch	500μm
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.004 inch
Housing Color	Beige
Contact Style	BELLOWED TYPE
Insulation Resistance	500000000Ohm
Contact Pattern	RECTANGULAR
Mating Cycles	20
Flat Flex Type	FFC, FPC
Connector/Contact Type	Contacts, Bottom
Cable End Type	Tapered
Locking Feature	Flip Lock
Actuator Color	Black
Height Above Board	0.037 0.95mm
FFC, FCB Thickness	0.30mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

FH19SC-9S-0.5SH(05) Product Details

FH19SC-9S-0.5SH(05) Overview

The packaging is FFC/FPC CONNECTOR.This device's mounting type is Surface Mount, Right Angle.It has been determined that a Tape & Reel (TR) case is necessary to package the product.It's part of the FH19SC Series.A number of benefits can be derived from the Solder Retention, Zero Insertion Force (ZIF) feature of this application.Part Surface Mount is mounted to the part.Operating temperature is -55°C~85°C.
