Name: 0527462070
Brand: Molex
SKU: 0527462070
Availability: InStock

new-10%

0527462070

Manufacturer part number:0527462070

Manufacturer:Molex

Description:0527462070 datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0527462070 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Phosphor Bronze
Mounting Type	Surface Mount, Right Angle
Housing Material	Polyamide (PA46), Nylon 4/6
Actuator Material	Polyphenylene Sulfide (PPS)
Operating Temperature	-20°C~85°C
Packaging	Tape & Reel (TR)
Series	Easy-On 52746
Feature	Solder Retention, Zero Insertion Force (ZIF)
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Number of Positions	20
Voltage - Rated	50V
Current Rating (Amps)	0.5A
Pitch	0.020 0.50mm
Contact Finish	Tin Bismuth
Flat Flex Type	FFC, FPC
Connector/Contact Type	Contacts, Bottom
Cable End Type	Straight
Locking Feature	Slide Lock
Height Above Board	0.079 2.00mm
FFC, FCB Thickness	0.30mm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0527462070 Product Details

0527462070 Overview

This device is mounted in the Surface Mount, Right Angle position.The product is packaged in a Tape & Reel (TR) case.It is part of the Easy-On 52746 Series of products.This feature renders it more powerful in a number of ways because of its Solder Retention, Zero Insertion Force (ZIF) feature.Operating temperature is set to -20°C~85°C.
