Name: FH23-17S-0.3SHAW(05)
Brand: Hirose Electric Co Ltd
SKU: FH23-17S-0.3SHAW(05)
Availability: InStock

new-10%

FH23-17S-0.3SHAW(05)

Manufacturer part number:FH23-17S-0.3SHAW(05)

Manufacturer:Hirose Electric Co Ltd

Description:FH23-17S-0.3SHAW(05) datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Hirose Electric Co Ltd stock available on our website

Case Package:SOT-23

Datasheet:FH23-17S-0.3SHAW(05) Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Contact Material	Phosphor Bronze
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Housing Material	Liquid Crystal Polymer (LCP), Halogen Free
Actuator Material	Liquid Crystal Polymer (LCP), Halogen Free
Operating Temperature	-55°C~85°C
Packaging	Tape & Reel (TR)
Series	FH23
JESD-609 Code	e4
Feature	Low Insertion Force (LIF)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Number of Positions	17
Number of Rows	1
Voltage - Rated	30V
Additional Feature	STAGGERED CONFIGURATION, LIF, ZIF
Subcategory	Headers and Edge Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	0.3A
Pitch	0.012 0.30mm
Total Number of Contacts	17
Reach Compliance Code	unknown
Current Rating	300mA
Reference Standard	UL
Contact Finish	Gold
Reliability	COMMERCIAL
Number Of PCB Rows	2
Lead Pitch	300μm
PCB Contact Pattern	STAGGERED
Mating Information	NO
Contact Gender	FEMALE
UL Flammability Code	94V-0
Housing Color	Beige
Insulation Resistance	50000000Ohm
Dielectric Withstanding Voltage	90VAC V
Contact Pattern	STAGGERED
Insertion Force-Max	LIF N
Mating Cycles	10
Flat Flex Type	FPC
Connector/Contact Type	Contacts, Bottom
Cable End Type	Tapered
Locking Feature	Flip Lock
Actuator Color	Black
Width	4.7mm
Height Above Board	0.049 1.25mm
FFC, FCB Thickness	0.20mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

FH23-17S-0.3SHAW(05) Product Details

FH23-17S-0.3SHAW(05) Overview

There is a Surface Mount, Right Angle mounting type for the device.Tape & Reel (TR) cases are used to package the product.FH23 Series product.There are also other features like STAGGERED CONFIGURATION, LIF, ZIF, to name a few.In many ways, it is more powerful due to its Low Insertion Force (LIF) feature.Surface Mount is mounting the part.There is no operating temperature for the device.
