Name: 5034256191
Brand: Molex
SKU: 5034256191
Availability: InStock

new-10%

5034256191

Manufacturer part number:5034256191

Manufacturer:Molex

Description:5034256191 datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:5034256191 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	9 Weeks
Contact Material	Copper Alloy
Mounting Type	Surface Mount, Right Angle
Housing Material	Liquid Crystal Polymer (LCP), Glass Filled
Mounting Option 1	LOCKING
Actuator Material	Polyphenylene Sulfide (PPS), Glass Filled
Operating Temperature	-40°C~85°C
Packaging	Tape & Reel (TR)
Published	2010
Series	BackFlip, Easy-On 503425
JESD-609 Code	e4
Feature	Solder Retention
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Number of Positions	61
Number of Rows	1
Voltage - Rated	50V
HTS Code	8536.69.40.51
Subcategory	Headers and Edge Type Connectors
Current Rating (Amps)	0.2A
Pitch	0.012 0.30mm
Total Number of Contacts	61
Contact Finish	Gold
Reliability	COMMERCIAL
PCB Contact Pattern	RECTANGULAR
Housing Color	White
Contact Resistance	80mOhm
Insulation Resistance	50000000Ohm
Contact Pattern	RECTANGULAR
Mating Cycles	10
Flat Flex Type	FPC
Connector/Contact Type	Contacts, Top and Bottom
Cable End Type	Notched
Locking Feature	Flip Lock, Backlock
Actuator Color	Black
Contact Finish Thickness	3.94μin 0.10μm
Height Above Board	0.047 1.20mm
FFC, FCB Thickness	0.20mm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

5034256191 Product Details

5034256191 Overview

This device has a Surface Mount, Right Angle mounting type.Tape & Reel (TR) cases are used to package the product.It's from the BackFlip, Easy-On 503425 Series.Its Solder Retention feature renders it more powerful in many ways.Operating temperature is -40°C~85°C.
