Name: STL52N25M5
Brand: STMicroelectronics
SKU: STL52N25M5
Availability: InStock

new-10%

STL52N25M5

Manufacturer part number:STL52N25M5

Manufacturer:STMicroelectronics

Description:Trans MOSFET N-CH 250V 28A 8-Pin Power Flat T/R

Case Package:SOT-23

Datasheet:STL52N25M5 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	8-PowerVDFN
Number of Pins	8
Transistor Element Material	SILICON
Operating Temperature	-55°C~150°C TJ
Packaging	Tape & Reel (TR)
Series	MDmesh™ V
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	5
ECCN Code	EAR99
Resistance	65mOhm
Additional Feature	ULTRA LOW-ON RESISTANCE
Subcategory	FET General Purpose Power
Technology	MOSFET (Metal Oxide)
Terminal Form	FLAT
Base Part Number	STL52
Pin Count	8
JESD-30 Code	R-PDSO-F5
Number of Elements	1
Power Dissipation-Max	2.5W Ta 110W Tc
Element Configuration	Dual
Operating Mode	ENHANCEMENT MODE
Power Dissipation	110W
Case Connection	DRAIN
Turn On Delay Time	40 ns
FET Type	N-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	65m Ω @ 14A, 10V
Vgs(th) (Max) @ Id	5V @ 100μA
Input Capacitance (Ciss) (Max) @ Vds	1770pF @ 50V
Current - Continuous Drain (Id) @ 25°C	28A Tc
Gate Charge (Qg) (Max) @ Vgs	47nC @ 10V
Rise Time	18ns
Drive Voltage (Max Rds On,Min Rds On)	10V
Vgs (Max)	±25V
Fall Time (Typ)	82 ns
Turn-Off Delay Time	64 ns
Continuous Drain Current (ID)	28A
Gate to Source Voltage (Vgs)	25V
Drain Current-Max (Abs) (ID)	4.2A
Drain to Source Breakdown Voltage	250V
Avalanche Energy Rating (Eas)	230 mJ
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
