Name: AOL1412
Brand: Alpha & Omega Semiconductor Inc.
SKU: AOL1412
Availability: InStock

new-10%

AOL1412

Manufacturer part number:AOL1412

Manufacturer:Alpha & Omega Semiconductor Inc.

Description:MOSFET N-CH 30V 85A 8ULTRASO

Case Package:SOT-23

Datasheet:AOL1412 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	3-PowerSMD, Flat Leads
Number of Pins	3
Transistor Element Material	SILICON
Operating Temperature	-55°C~150°C TJ
Packaging	Tape & Reel (TR)
Published	2010
Series	SRFET™
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
ECCN Code	EAR99
Technology	MOSFET (Metal Oxide)
Terminal Position	DUAL
Pin Count	3
Qualification Status	Not Qualified
Number of Elements	1
Configuration	SINGLE WITH BUILT-IN DIODE
Power Dissipation-Max	2.1W Ta 36W Tc
Operating Mode	ENHANCEMENT MODE
Case Connection	DRAIN
FET Type	N-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	3.9m Ω @ 20A, 10V
Vgs(th) (Max) @ Id	2.4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds	7716pF @ 15V
Current - Continuous Drain (Id) @ 25°C	17A Ta 70A Tc
Gate Charge (Qg) (Max) @ Vgs	115nC @ 10V
Drain to Source Voltage (Vdss)	30V
Drive Voltage (Max Rds On,Min Rds On)	4.5V 10V
Vgs (Max)	±12V
Continuous Drain Current (ID)	70A
Drain Current-Max (Abs) (ID)	85A
Drain-source On Resistance-Max	0.0046Ohm
Pulsed Drain Current-Max (IDM)	200A
Avalanche Energy Rating (Eas)	110 mJ
FET Feature	Schottky Diode (Body)
RoHS Status	RoHS Compliant

About AOL1412

The AOL1412 from Alpha & Omega Semiconductor Inc. is a high-performance microcontroller designed for a wide range of embedded applications. This component features MOSFET N-CH 30V 85A 8ULTRASO.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the AOL1412, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
