Name: 929870-01-13-RA
Brand: 3M
SKU: 929870-01-13-RA
Availability: InStock

new-10%

929870-01-13-RA

Manufacturer part number:929870-01-13-RA

Manufacturer:3M

Description:929870-01-13-RA datasheet pdf and Rectangular Connectors - Headers, Receptacles, Female Sockets product details from 3M stock available on our website

Case Package:SOT-23

Datasheet:929870-01-13-RA Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Material	Copper Alloy
Contact Plating	Gold
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Polybutylene Terephthalate (PBT), Glass Filled
Housing Material	Polyester
Operating Temperature	-40°C~105°C
Packaging	Bulk
Published	2007
Series	929
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Receptacle
Number of Positions	13
Color	Black
Number of Rows	1
Gender	Female
Voltage - Rated	1000V
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Type	Forked
Current Rating (Amps)	1A
Pitch	2.54mm
Insulation Height	0.150 3.81mm
Style	Board to Board
Number of Positions Loaded	All
Current Rating	1A
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Contact Length - Post	0.125 3.18mm
Contact Finish - Post	Tin
Contact Gender	Female
Housing Color	Black
Height	3.8mm
Length	33mm
Width	2.54mm
Contact Finish Thickness - Mating	10.0μin 0.25μm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Lead Free	Lead Free

929870-01-13-RA Product Details

929870-01-13-RA Overview

This product is packaged in a Receptacle box.Through Hole is the mount type.Packaging for the product is carried out via a Bulk case.This is from the 929 Series.In this case, Through Hole mounts the part.The device is operating at -40°C~105°C Operating Temperature.
