B32520C1224K189

  • B32520C1224K189 - B32520 0.22μF Film Capacitor ±10% Radial PC Pins 100V-DC 63V-AC Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked Through Hole
  • B32520C1224K189 - B32520 0.22μF Film Capacitor ±10% Radial PC Pins 100V-DC 63V-AC Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked Through Hole

B32520C1224K189

B32520C1224K189

TDK Electronics Inc.

B32520 0.22μF Film Capacitor ±10% Radial PC Pins 100V-DC 63V-AC Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked Through Hole

SOT-23

B32520C1224K189 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 14 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Contact PlatingTin
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Dielectric MaterialPolyester, Polyethylene Terephthalate (PET), Metallized - Stacked
Operating Temperature-55°C~125°C
PackagingTape & Reel (TR)
Series B32520
Size / Dimension 0.394Lx0.118W 10.00mmx3.00mm
Tolerance ±10%
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature125°C
Min Operating Temperature -55°C
Applications Automotive; EMI, RFI Suppression
Voltage - Rated 100V
Capacitance 0.22μF
Voltage - Rated DC 100V
Depth 3mm
Voltage - Rated AC 63V
Lead Pitch 7.5mm
Dielectric PET
Lead Spacing0.295 7.50mm
Lead Diameter 500 μm
Voltage 100V
Height 8mm
Height Seated (Max) 0.315 8.00mm
Length 10mm
Width 2.9972mm
Radiation HardeningNo
RoHS StatusROHS3 Compliant
Lead Free Lead Free
In-Stock:14384 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$0.532920$0.53292
10$0.502755$5.02755
100$0.474297$47.4297
500$0.447450$223.725
1000$0.422122$422.122

B32520C1224K189 Product Details

B32520C1224K189 Overview


Electrical devices have 0.295 7.50mm lead spacing.Temperatures of -55°C~125°C are suitable for operating the device.

B32520C1224K189 Features




B32520C1224K189 Applications


There are a lot of TDK Electronics Inc.
B32520C1224K189 applications of film capacitors.


  • RF Modules
  • Mobile communications
  • Satellite TV
  • Global positioning systems
  • Filters
  • VCO's
  • Matching networks
  • Snubbering
  • Filtering
  • IGBT
