Name: IRFU1205
Brand: Infineon Technologies
SKU: IRFU1205
Availability: InStock

new-10%

IRFU1205

Manufacturer part number:IRFU1205

Manufacturer:Infineon Technologies

Description:MOSFET N-CH 55V 44A I-PAK

Case Package:SOT-23

Datasheet:IRFU1205 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Through Hole
Package / Case	TO-251-3 Short Leads, IPak, TO-251AA
Surface Mount	NO
Transistor Element Material	SILICON
Operating Temperature	-55°C~175°C TJ
Packaging	Tube
Published	1998
Series	HEXFET®
JESD-609 Code	e0
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn/Pb)
Additional Feature	AVALANCHE RATED, ULTRA LOW RESISTANCE
Technology	MOSFET (Metal Oxide)
Terminal Position	SINGLE
Peak Reflow Temperature (Cel)	245
[email protected] Reflow Temperature-Max (s)	30
JESD-30 Code	R-PSIP-T3
Qualification Status	Not Qualified
Number of Elements	1
Configuration	SINGLE WITH BUILT-IN DIODE
Power Dissipation-Max	107W Tc
Operating Mode	ENHANCEMENT MODE
Case Connection	DRAIN
FET Type	N-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	27m Ω @ 26A, 10V
Vgs(th) (Max) @ Id	4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds	1300pF @ 25V
Current - Continuous Drain (Id) @ 25°C	44A Tc
Gate Charge (Qg) (Max) @ Vgs	65nC @ 10V
Drain to Source Voltage (Vdss)	55V
Drive Voltage (Max Rds On,Min Rds On)	10V
Vgs (Max)	±20V
Drain Current-Max (Abs) (ID)	20A
Drain-source On Resistance-Max	0.027Ohm
Pulsed Drain Current-Max (IDM)	160A
DS Breakdown Voltage-Min	55V
Avalanche Energy Rating (Eas)	210 mJ
RoHS Status	Non-RoHS Compliant

About IRFU1205

The IRFU1205 from Infineon Technologies is a high-performance microcontroller designed for a wide range of embedded applications. This component features MOSFET N-CH 55V 44A I-PAK.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the IRFU1205, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
