Name: AUIRL7766M2TR
Brand: Infineon Technologies
SKU: AUIRL7766M2TR
Availability: InStock

new-10%

AUIRL7766M2TR

Manufacturer part number:AUIRL7766M2TR

Manufacturer:Infineon Technologies

Description:MOSFET N-CH 100V 10A DIRECTFET

Case Package:SOT-23

Datasheet:AUIRL7766M2TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	DirectFET™ Isometric M4
Number of Pins	9
Transistor Element Material	SILICON
Operating Temperature	-55°C~175°C TJ
Packaging	Tape & Reel (TR)
Published	2011
Series	HEXFET®
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	5
Terminal Finish	Matte Tin (Sn)
Additional Feature	HIGH RELIABILITY, LOGIC LEVEL COMPATIBLE
Subcategory	FET General Purpose Power
Technology	MOSFET (Metal Oxide)
Terminal Position	BOTTOM
JESD-30 Code	R-XBCC-N5
Number of Elements	1
Configuration	SINGLE WITH BUILT-IN DIODE
Power Dissipation-Max	2.5W Ta 62.5W Tc
Operating Mode	ENHANCEMENT MODE
Power Dissipation	62.5W
Case Connection	DRAIN
Turn On Delay Time	16 ns
FET Type	N-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	10m Ω @ 31A, 10V
Vgs(th) (Max) @ Id	2.5V @ 150μA
Input Capacitance (Ciss) (Max) @ Vds	5305pF @ 25V
Current - Continuous Drain (Id) @ 25°C	10A Ta
Gate Charge (Qg) (Max) @ Vgs	66nC @ 4.5V
Rise Time	24ns
Drive Voltage (Max Rds On,Min Rds On)	4.5V 10V
Vgs (Max)	±16V
Fall Time (Typ)	49 ns
Turn-Off Delay Time	120 ns
Continuous Drain Current (ID)	10A
Threshold Voltage	2.5V
Gate to Source Voltage (Vgs)	16V
Drain Current-Max (Abs) (ID)	51A
Drain-source On Resistance-Max	0.01Ohm
Drain to Source Breakdown Voltage	100V
Pulsed Drain Current-Max (IDM)	204A
Avalanche Energy Rating (Eas)	237 mJ
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant
