Name: IRF7807VD2PBF
Brand: Infineon Technologies
SKU: IRF7807VD2PBF
Availability: InStock

new-10%

IRF7807VD2PBF

Manufacturer part number:IRF7807VD2PBF

Manufacturer:Infineon Technologies

Description:MOSFET N-CH 30V 8.3A 8-SOIC

Case Package:SOT-23

Datasheet:IRF7807VD2PBF Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154, 3.90mm Width)
Number of Pins	8
Supplier Device Package	8-SO
Operating Temperature	-55°C~150°C TJ
Packaging	Tube
Published	2004
Series	FETKY™
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	SMD/SMT
Resistance	25MOhm
Max Operating Temperature	150°C
Min Operating Temperature	-55°C
Voltage - Rated DC	30V
Technology	MOSFET (Metal Oxide)
Current Rating	8.3A
Number of Elements	1
Power Dissipation-Max	2.5W Ta
Power Dissipation	2.5W
Turn On Delay Time	6.3 ns
Forward Current	3.7A
FET Type	N-Channel
Rds On (Max) @ Id, Vgs	25mOhm @ 7A, 4.5V
Vgs(th) (Max) @ Id	1V @ 250μA
Current - Continuous Drain (Id) @ 25°C	8.3A Ta
Gate Charge (Qg) (Max) @ Vgs	14nC @ 4.5V
Rise Time	1.2ns
Drain to Source Voltage (Vdss)	30V
Drive Voltage (Max Rds On,Min Rds On)	4.5V
Vgs (Max)	±20V
Forward Voltage	540mV
Fall Time (Typ)	2.2 ns
Turn-Off Delay Time	1.1 ns
Continuous Drain Current (ID)	8.3A
Threshold Voltage	1V
Gate to Source Voltage (Vgs)	20V
Drain to Source Breakdown Voltage	30V
Dual Supply Voltage	30V
FET Feature	Schottky Diode (Isolated)
Drain to Source Resistance	25mOhm
Rds On Max	25 mΩ
Nominal Vgs	1 V
Height	1.4986mm
Length	4.9784mm
Width	3.9878mm
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Lead Free	Lead Free
