Name: TPS71247DRCR
Brand: Texas Instruments
SKU: TPS71247DRCR
Price: 1.34000 USD
Availability: InStock

new-10%

TPS71247DRCR

Manufacturer part number:TPS71247DRCR

Manufacturer:Texas Instruments

Description:Enable, Power Good Fixed 0.5mm TPS71247 PMIC 10 10-VFDFN Exposed Pad

Case Package:SOT-23

Datasheet:TPS71247DRCR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 2 days ago)
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	10-VFDFN Exposed Pad
Surface Mount	YES
Number of Pins	10
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	10
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Packing Method	TR
Max Power Dissipation	1.92W
Terminal Position	DUAL
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	0.5mm
Base Part Number	TPS71247
Pin Count	10
Current - Supply (Max)	600μA
Number of Outputs	2
Voltage - Input (Max)	5.5V
Output Voltage	2.85V
Output Type	Fixed
Max Output Current	200mA
Output Configuration	Positive
Current - Output	250mA
Quiescent Current	300μA
Control Features	Enable, Power Good
Accuracy	1.5 %
Max Output Voltage	1.8V
Output Voltage 1	1.8V
Voltage - Output (Min/Fixed)	1.8V 2.85V
Number of Regulators	2
Min Input Voltage	2.7V
Protection Features	Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq)	250μA
Voltage Dropout (Max)	0.4V @ 500mA
PSRR	59dB ~ 54dB (120Hz)
Dropout Voltage	125mV
Dropout Voltage1-Nom	0.125V
Min Output Voltage	1.8V
Voltage Tolerance-Max	3%
Min Current Limit	400mA
Input Bias Current	190μA
Output Voltage 2	2.85V
Height	1mm
Length	3mm
Width	3mm
Thickness	900μm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

TPS71247DRCR Product Details

TPS71247DRCR Overview

This Voltage Regulator IC comes inTape & Reel (TR) packaging. This battery regulator is contained in a 10-VFDFN Exposed Pad package. There are 10 terminations on the gadget. The IC chip's output type is Fixed. This electronic component implements 2 regulators. The Linear Voltage Regulator's mounting type is Surface Mount. The IC Regulator is set to operate at -40°C~125°C degrees. This regulator's output function is configured to be Positive. Its current output stands at 250mA. IC voltage regulator has a sum of 10 pins. To ensure prompt, sufficient performance, this part features 2 outputs in total. Its dropout voltage is 10 volts. The component's pin number remains 10. FYI, the basic part number for this IC regulator is TPS71247. The way of packing the voltage regulator IC is TR. It works in 200mA output current at mostIt operates in the 300μA Quiescent Current state.
