Name: SMM-110-02-SM-S-K-TR
Brand: Samtec Inc.
SKU: SMM-110-02-SM-S-K-TR
Price: 4.00000 USD
Availability: InStock

new-10%

SMM-110-02-SM-S-K-TR

Manufacturer part number:SMM-110-02-SM-S-K-TR

Manufacturer:Samtec Inc.

Description:1 Rows Receptacle Solder Beryllium Copper Surface Mount Tape & Reel (TR) Gold Liquid Crystal Polymer (LCP) 10 Positions Female Socket

Case Package:SOT-23

Datasheet:SMM-110-02-SM-S-K-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Contact Material	Beryllium Copper
Mounting Type	Surface Mount
Contact Shape	Square
Insulation Material	Liquid Crystal Polymer (LCP)
Housing Material	Polymer
Operating Temperature	-55°C~125°C
Packaging	Tape & Reel (TR)
Published	2017
Series	Tiger Eye™ SMM
Feature	Pick and Place
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Receptacle
Number of Positions	10
Number of Rows	1
Gender	Female
Voltage - Rated	350VAC
HTS Code	8536.69.40.40
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Type	Female Socket
Current Rating (Amps)	3.2A per Contact
Orientation	Straight
Depth	2mm
Insulation Height	0.140 3.56mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Pitch - Mating	0.079 2.00mm
Insulation Color	Black
Contact Finish - Post	Tin
Contact Resistance	10mOhm
Max Voltage Rating (AC)	350V
Max Current Rating	3.9A
Length	20mm
Contact Finish Thickness - Mating	30.0μin 0.76μm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

SMM-110-02-SM-S-K-TR Product Details

SMM-110-02-SM-S-K-TR Overview

Packaging is Receptacle.Surface Mount is the mounting type.Packaging for the product is carried out via a Tape & Reel (TR) case.As a product of the Tiger Eye™ SMM Series, it can be found in this category.With its Pick and Place feature, it is more powerful in many ways.The device is operating at -55°C~125°C Operating Temperature.
