Name: HLE-102-02-SM-DV-BE-TR
Brand: Samtec Inc.
SKU: HLE-102-02-SM-DV-BE-TR
Availability: InStock

new-10%

HLE-102-02-SM-DV-BE-TR

Manufacturer part number:HLE-102-02-SM-DV-BE-TR

Manufacturer:Samtec Inc.

Description:2 RowsReceptacle, Bottom EntrySolderBeryllium CopperSurface MountTape & Reel (TR)GoldLiquid Crystal Polymer (LCP)4 PositionsFemale Socket

Case Package:SOT-23

Datasheet:HLE-102-02-SM-DV-BE-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	Beryllium Copper
Mounting Type	Surface Mount
Contact Shape	Square
Insulation Material	Liquid Crystal Polymer (LCP)
Operating Temperature	-55°C~125°C
Packaging	Tape & Reel (TR)
Published	2016
Series	HLE
JESD-609 Code	e3
Part Status	Active
Termination	Solder
Connector Type	Receptacle, Bottom Entry
Number of Positions	4
Number of Rows	2
Gender	Female
Voltage - Rated	400VAC
Additional Feature	BOTTOM ENTRY, TIGER BEAM CONTACT
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Female Socket
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	4.1A per Contact
Total Number of Contacts	4
Insulation Height	0.144 3.66mm
Style	Board to Board
Number of Positions Loaded	All
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Row Spacing - Mating	0.100 (2.54mm)
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	30.0μin 0.76μm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

HLE-102-02-SM-DV-BE-TR Product Details

HLE-102-02-SM-DV-BE-TR Overview

The packaging contains Receptacle, Bottom Entry.The device's mounting type is Surface Mount.A Tape & Reel (TR) case is used to package the product.The product is a member of the HLE Series.Besides that, there's also BOTTOM ENTRY, TIGER BEAM CONTACT, to name a few.-55°C~125°C Operating Temperature is the default operating temperature for the device.
