ECH-U1C273JX5

  • ECH-U1C273JX5 - ECH-U(X) 0.027μF Film Capacitor ±5% 1206 (3216 Metric) Solder Pads 16V-DC 16V-AC Polyphenylene Sulfide (PPS), Metallized - Stacked PCB, Surface Mount
  • ECH-U1C273JX5 - ECH-U(X) 0.027μF Film Capacitor ±5% 1206 (3216 Metric) Solder Pads 16V-DC 16V-AC Polyphenylene Sulfide (PPS), Metallized - Stacked PCB, Surface Mount

ECH-U1C273JX5

ECH-U1C273JX5

Panasonic Electronic Components

ECH-U(X) 0.027μF Film Capacitor ±5% 1206 (3216 Metric) Solder Pads 16V-DC 16V-AC Polyphenylene Sulfide (PPS), Metallized - Stacked PCB, Surface Mount

SOT-23

ECH-U1C273JX5 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 8 Weeks
Contact PlatingCopper, Silver, Tin
Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case 1206 (3216 Metric)
Terminal Shape WRAPAROUND
Material Ceramic
Dielectric MaterialPolyphenylene Sulfide (PPS), Metallized - Stacked
Operating Temperature-55°C~125°C
PackagingTape & Reel (TR)
Published 2000
Series ECH-U(X)
Size / Dimension 0.126Lx0.063W 3.20mmx1.60mm
Tolerance ±5%
JESD-609 Code e1
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Solder Pads
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Applications General Purpose
HTS Code8532.25.00.45
Capacitance 0.027μF
Voltage - Rated DC 16V
Packing Method TR, 7 INCH
Depth 1.6mm
Voltage - Rated AC 16V
Case Code (Metric) 3216
Case Code (Imperial) 1206
Capacitor Type FILM CAPACITOR
Dielectric PPS
Insulation Resistance3GOhm
Size Code 1306
Voltage 16V
Height 1.1mm
Height Seated (Max) 0.051 1.30mm
Length 3.2mm
RoHS StatusROHS3 Compliant
Lead Free Contains Lead
In-Stock:8707 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$0.052025$0.052025
500$0.038253$19.1265
1000$0.031877$31.877
2000$0.029245$58.49
5000$0.027333$136.665
10000$0.025425$254.25
15000$0.024590$368.85
50000$0.024178$1208.9

ECH-U1C273JX5 Product Details

ECH-U1C273JX5 Overview


There is 3GOhm insulation resistance from the device.-55°C~125°C is the maximum temperature at which the device can operate.

ECH-U1C273JX5 Features


3GOhm insulation resistance

ECH-U1C273JX5 Applications


There are a lot of Panasonic Electronic Components ECH-U1C273JX5 applications of film capacitors.

  • Mobile communications
  • Bypassing
  • Coupling, decoupling
  • Blocking
  • Test and measuring equipment
  • Matching networks
  • Filters
  • TV and monitor sets
  • Switch mode power supplies
  • Electronic ballasts
