B32756G4505K000

  • B32756G4505K000 - B32756 5μF Film Capacitor ±10% Radial - 4 Leads PC Pins 800V-DC 400V-AC Polypropylene (PP), Metallized
  • B32756G4505K000 - B32756 5μF Film Capacitor ±10% Radial - 4 Leads PC Pins 800V-DC 400V-AC Polypropylene (PP), Metallized

B32756G4505K000

B32756G4505K000

TDK Electronics Inc.

B32756 5μF Film Capacitor ±10% Radial - 4 Leads PC Pins 800V-DC 400V-AC Polypropylene (PP), Metallized

SOT-23

B32756G4505K000 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 17 Weeks
Mounting Type Through Hole
Package / Case Radial - 4 Leads
Dielectric MaterialPolypropylene (PP), Metallized
Operating Temperature-40°C~105°C
PackagingBulk
Series B32756
Size / Dimension 1.654Lx0.866W 42.00mmx22.00mm
Tolerance ±10%
Part StatusActive
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pins
Applications General Purpose
Capacitance 5μF
Voltage - Rated DC 800V
Voltage - Rated AC 400V
ESR (Equivalent Series Resistance) 5.3mOhms
Lead Spacing1.476 37.50mm
Height Seated (Max) 1.772 45.00mm
RoHS StatusROHS3 Compliant
In-Stock:651 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$8.474305$8.474305
10$7.994627$79.94627
100$7.542101$754.2101
500$7.115191$3557.5955
1000$6.712444$6712.444

B32756G4505K000 Product Details

B32756G4505K000 Overview


A device with a 5.3mOhms ESR (Equivalent Series Resistance) has been identified.Lead spacing is 1.476 37.50mm for this electrical device.-40°C~105°C is the maximum temperature at which the device can operate.

B32756G4505K000 Features


5.3mOhms equivalent series resistance (ESR)

B32756G4505K000 Applications


There are a lot of TDK Electronics Inc. B32756G4505K000 applications of film capacitors.

  • RFI for automotive
  • Satellite TV
  • Filters
  • Switch mode power supplies
  • Coupling, decoupling
  • Matching networks
  • Compact fluorescent lamps (CFL)
  • Industrial and automotive inverters
  • Battery management system
  • Filtering
