Name: BUK7607-30B,118
Brand: Nexperia USA Inc.
SKU: BUK7607-30B,118
Availability: InStock

new-10%

BUK7607-30B,118

Manufacturer part number:BUK7607-30B,118

Manufacturer:Nexperia USA Inc.

Description:MOSFET N-CH 30V 75A D2PAK

Case Package:SOT-23

Datasheet:BUK7607-30B,118 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Contact Plating	Tin
Mounting Type	Surface Mount
Package / Case	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Surface Mount	YES
Number of Pins	3
Transistor Element Material	SILICON
Operating Temperature	-55°C~175°C TJ
Packaging	Tape & Reel (TR)
Published	2011
Series	Automotive, AEC-Q101, TrenchMOS™
JESD-609 Code	e3
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
HTS Code	8541.29.00.75
Subcategory	FET General Purpose Power
Technology	MOSFET (Metal Oxide)
Terminal Form	GULL WING
Pin Count	3
JESD-30 Code	R-PSSO-G2
Number of Elements	1
Power Dissipation-Max	157W Tc
Element Configuration	Single
Operating Mode	ENHANCEMENT MODE
Power Dissipation	157W
Case Connection	DRAIN
Turn On Delay Time	20 ns
FET Type	N-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	7m Ω @ 25A, 10V
Vgs(th) (Max) @ Id	4V @ 1mA
Input Capacitance (Ciss) (Max) @ Vds	2427pF @ 25V
Current - Continuous Drain (Id) @ 25°C	75A Tc
Gate Charge (Qg) (Max) @ Vgs	36nC @ 10V
Rise Time	51ns
Drive Voltage (Max Rds On,Min Rds On)	10V
Vgs (Max)	±20V
Fall Time (Typ)	44 ns
Turn-Off Delay Time	51 ns
Continuous Drain Current (ID)	108A
Gate to Source Voltage (Vgs)	20V
Max Dual Supply Voltage	30V
Drain Current-Max (Abs) (ID)	75A
Drain-source On Resistance-Max	0.007Ohm
Drain to Source Breakdown Voltage	30V
Radiation Hardening	No
RoHS Status	RoHS Compliant

About BUK7607-30B,118

The BUK7607-30B,118 from Nexperia USA Inc. is a high-performance microcontroller designed for a wide range of embedded applications. This component features MOSFET N-CH 30V 75A D2PAK.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the BUK7607-30B,118, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
