Name: IRFR3704ZTRRPBF
Brand: Infineon Technologies
SKU: IRFR3704ZTRRPBF
Availability: InStock

new-10%

IRFR3704ZTRRPBF

Manufacturer part number:IRFR3704ZTRRPBF

Manufacturer:Infineon Technologies

Description:MOSFET N-CH 20V 60A DPAK

Case Package:SOT-23

Datasheet:IRFR3704ZTRRPBF Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins	3
Supplier Device Package	D-Pak
Operating Temperature	-55°C~175°C TJ
Packaging	Tape & Reel (TR)
Published	2004
Series	HEXFET®
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Max Operating Temperature	175°C
Min Operating Temperature	-55°C
Technology	MOSFET (Metal Oxide)
Number of Elements	1
Power Dissipation-Max	48W Tc
Element Configuration	Single
Power Dissipation	48W
Turn On Delay Time	8.4 ns
FET Type	N-Channel
Rds On (Max) @ Id, Vgs	8.4mOhm @ 15A, 10V
Vgs(th) (Max) @ Id	2.55V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds	1190pF @ 10V
Current - Continuous Drain (Id) @ 25°C	60A Tc
Gate Charge (Qg) (Max) @ Vgs	14nC @ 4.5V
Rise Time	8.9ns
Drain to Source Voltage (Vdss)	20V
Drive Voltage (Max Rds On,Min Rds On)	4.5V 10V
Vgs (Max)	±20V
Fall Time (Typ)	12 ns
Turn-Off Delay Time	4.9 ns
Continuous Drain Current (ID)	60A
Gate to Source Voltage (Vgs)	20V
Drain to Source Breakdown Voltage	20V
Input Capacitance	1.19nF
Drain to Source Resistance	8.4mOhm
Rds On Max	8.4 mΩ
Height	2.38mm
Length	6.7056mm
Width	6.22mm
Radiation Hardening	No
RoHS Status	RoHS Compliant
