FX6A-20S-0.8SV2(71)

  • FX6A-20S-0.8SV2(71) - FX6A-20S-0.8SV2(71) datasheet pdf and Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) product details from Hirose Electric Co Ltd stock available on our website
  • FX6A-20S-0.8SV2(71) - FX6A-20S-0.8SV2(71) datasheet pdf and Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) product details from Hirose Electric Co Ltd stock available on our website

FX6A-20S-0.8SV2(71)

FX6A-20S-0.8SV2(71)

Hirose Electric Co Ltd

FX6A-20S-0.8SV2(71) datasheet pdf and Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) product details from Hirose Electric Co Ltd stock available on our website

SOT-23

FX6A-20S-0.8SV2(71) Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 10 Weeks
Contact MaterialPHOSPHOR BRONZE
Mounting Type Surface Mount
Insulation Material POLYPHENYLENE SULPHIDE
Mounting Option 1 GUIDE SLOT
Mounting Option 2 LOCKING
PackagingTray
Series FX6
JESD-609 Code e2
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Center Strip Contacts
Number of Positions 20
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Pitch 0.031 0.80mm
Total Number of Contacts 20
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 85°C
Contact Gender FEMALE
Operating Temperature (Min) -55°C
Rated Current (Signal) 0.5A
Contact Style BELLOWED TYPE
Contact Resistance 40mOhm
Insulation Resistance100000000Ohm
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 300VAC V
PCB Contact Row Spacing 4.8006 mm
Durability 100 Cycles
Contact Pattern RECTANGULAR
Height Above Board 0.236 6.00mm
Stack Height (Mating) 7mm 8mm 9mm
Radiation HardeningNo
RoHS StatusRoHS Compliant
In-Stock:2471 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$2.93000$2.93
20$2.80800$56.16
40$2.57400$102.96
60$2.45700$147.42
100$2.34000$234
260$2.04750$532.35
500$1.98900$994.5

FX6A-20S-0.8SV2(71) Product Details

FX6A-20S-0.8SV2(71) Overview


It comes in Receptacle, Center Strip Contacts packaging.This product is packaged in a case marked Tray.The device's mounting type is Surface Mount.There is a product in the FX6 Series.

FX6A-20S-0.8SV2(71) Features


FX6 series
Package / Case: Tray
Mounting Type:Surface Mount

FX6A-20S-0.8SV2(71) Applications


There are a lot of Hirose Electric Co Ltd FX6A-20S-0.8SV2(71) Rectangular Connectors applications.

  • Data Technology
  • Embedded systems
  • Transportation
  • Measuring & Control Technology
  • Military Technology
  • Instrumentation
  • Industrial Automation
  • Communication
  • Telecommunications
  • Medical technology
