09041326952

new-10%

Manufacturer part number:09041326952

Manufacturer:HARTING

Description:09041326952 datasheet pdf and Backplane Connectors - DIN 41612 product details from HARTING stock available on our website

Case Package:SOT-23

Datasheet:09041326952 Datasheet

RoHs Status:non-compliant

Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	PBT
Material - Insulation	Polybutylene Terephthalate (PBT), Glass Filled
Operating Temperature	-55°C~125°C
Packaging	Bulk
Series	DIN 41612
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header, Male Pins
Number of Positions	32 (Power)
Number of Rows	2
MIL Conformance	NO
DIN Conformance	YES
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.200 5.08mm
Total Number of Contacts	32
Style	D
Number of Positions Loaded	All
Current Rating	6A
Contact Finish	Gold
Reliability	COMMERCIAL
Body Length or Diameter	3.701 inch
Number Of PCB Rows	2
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.433 inch
UL Flammability Code	94V-0
Empty Shell	NO
Rated Current (Signal)	6A
Contact Resistance	15mOhm
Insulation Resistance	1000000000000Ohm
Dielectric Withstanding Voltage	1550VAC V
PCB Contact Row Spacing	5.08 mm
Durability	400 Cycles
Insertion Force-Max	1.5568 N
Name of Rows Loaded	A,C
Length - Termination	0.118 inch
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant
Flammability Rating	UL94 V-0
