Name: 0524372272
Brand: Molex
SKU: 0524372272
Availability: InStock

new-10%

0524372272

Manufacturer part number:0524372272

Manufacturer:Molex

Description:0524372272 datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0524372272 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Phosphor Bronze
Mounting Type	Surface Mount, Right Angle
Housing Material	Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Option 1	LOCKING
Actuator Material	Polyphenylene Sulfide (PPS), Glass Filled
Board Mounting Option	FITTING NAIL
Operating Temperature	-40°C~85°C
Packaging	Tape & Reel (TR)
Series	Easy-On 52437
JESD-609 Code	e6
Feature	Solder Retention, Zero Insertion Force (ZIF)
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	FFC/FPC CONNECTOR
Number of Positions	22
Number of Rows	1
Voltage - Rated	50V
HTS Code	8536.69.40.51
Subcategory	Headers and Edge Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	0.5A
Pitch	0.020 0.50mm
Total Number of Contacts	22
Reference Standard	UL
Contact Finish	Tin Bismuth
Reliability	COMMERCIAL
Body Length or Diameter	0.614 inch
Number Of PCB Rows	1
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.079 inch
Contact Gender	FEMALE
UL Flammability Code	94V-0
Housing Color	White
Contact Style	DUAL PRONG
Insulation Resistance	50000000Ohm
Contact Pattern	RECTANGULAR
Insertion Force-Max	ZIF N
Withdrawl Force-Min	ZIF N
Mating Cycles	20
Flat Flex Type	FFC, FPC
Connector/Contact Type	Contacts, Bottom
Cable End Type	Straight
Locking Feature	Flip Lock
Actuator Color	Brown
Plating Thickness	39μin
Height Above Board	0.079 2.00mm
FFC, FCB Thickness	0.30mm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0524372272 Product Details

0524372272 Overview

This product is packaged in a FFC/FPC CONNECTOR box.Surface Mount, Right Angle is the mounting type.It's packaged in a Tape & Reel (TR) case.This product is from the Easy-On 52437 Series.In many ways, its Solder Retention, Zero Insertion Force (ZIF) feature makes it more powerful.In this case, the device operates at -40°C~85°C Operating Temperature.
