Name: 1597420000
Brand: Weidmüller
SKU: 1597420000
Price: 9.11000 USD
Availability: InStock

new

1597420000

Manufacturer part number:1597420000

Manufacturer:Weidmüller

Description:1597420000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1597420000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Contact Material	Copper Alloy
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Polybutylene Terephthalate (PBT)
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2004
Series	Omnimate BL
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	Not Applicable
Termination	Screw
ECCN Code	EAR99
Type	Plug, Female Sockets
Color	Orange
Number of Rows	1
Voltage - Rated DC	250V
Pitch	0.138 3.50mm
Orientation	Right Angle
Ingress Protection	IP20
Depth	18.5mm
Insulation Height	0.512 13.00mm
Current Rating	17A
Termination Style	Screw - Clamping Yoke (Tension Sleeve)
Voltage - Rated AC	250V
Approval Agency	CSA, UR
Voltage	300V
Max Supply Voltage	300V
Max Current Rating	10A
Number of Levels	1
Current	10A
Wire Gauge (Max)	28 AWG
Wire Gauge (Min)	14 AWG
Wire/Cable Gauge	28 AWG
Contact Mating Finish	Tin
Number of Decks	1
Wire Gauge or Range - AWG	14-28 AWG
Voltage - IEC	320V
Torque - Screw	0.2-0.25 Nm (1.7-2.2 Lb-In)
Number of Ways	8
Safety Approval	UL; IEC; VDE; CSA
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-1.5mm2
Current - IEC	17A
Number of Positions Per Level	8
Screw Size	M2
Stripping Length	6mm
Fastening Method	CONNECTOR
Length	28mm
Width	18.5mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1597420000 Product Details

1597420000 Overview

Mounting type Free Hanging (In-Line) is assigned to the device.It is necessary to use a Bulk case for packaging the product.There is a product in the Omnimate BL Series.There's a Cable, Free Hanging mount on the part.Operating temperature is -50°C~100°C.This chip should not be supplied with voltage greater than 300V volts.There are many benefits shared between this part and other Plug, Female Sockets products.
