Name: SI1965DH-T1-GE3
Brand: Vishay Siliconix
SKU: SI1965DH-T1-GE3
Price: 0.53000 USD
Availability: InStock

new-10%

SI1965DH-T1-GE3

Manufacturer part number:SI1965DH-T1-GE3

Manufacturer:Vishay Siliconix

Description:MOSFET 12V 1.3A 1.25W 390mohm @ 4.5V

Case Package:SOT-23

Datasheet:SI1965DH-T1-GE3 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	6-TSSOP, SC-88, SOT-363
Number of Pins	6
Weight	28.009329mg
Transistor Element Material	SILICON
Operating Temperature	-55°C~150°C TJ
Packaging	Tape & Reel (TR)
Published	2010
Series	TrenchFET®
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	6
ECCN Code	EAR99
Resistance	390mOhm
Terminal Finish	Matte Tin (Sn)
Subcategory	Other Transistors
Max Power Dissipation	1.25W
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
[email protected] Reflow Temperature-Max (s)	30
Base Part Number	SI1965
Pin Count	6
Number of Elements	2
Number of Channels	2
Element Configuration	Dual
Operating Mode	ENHANCEMENT MODE
Power Dissipation	740mW
Turn On Delay Time	12 ns
FET Type	2 P-Channel (Dual)
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	390m Ω @ 1A, 4.5V
Vgs(th) (Max) @ Id	1V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds	120pF @ 6V
Current - Continuous Drain (Id) @ 25°C	1.3A
Gate Charge (Qg) (Max) @ Vgs	4.2nC @ 8V
Rise Time	27ns
Drain to Source Voltage (Vdss)	12V
Fall Time (Typ)	10 ns
Turn-Off Delay Time	15 ns
Continuous Drain Current (ID)	1.14A
Gate to Source Voltage (Vgs)	8V
Drain Current-Max (Abs) (ID)	1.3A
Drain to Source Breakdown Voltage	-12V
FET Technology	METAL-OXIDE SEMICONDUCTOR
FET Feature	Logic Level Gate
Nominal Vgs	-400 mV
Radiation Hardening	No
REACH SVHC	Unknown
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

About SI1965DH-T1-GE3

The SI1965DH-T1-GE3 from Vishay Siliconix is a high-performance microcontroller designed for a wide range of embedded applications. This component features MOSFET 12V 1.3A 1.25W 390mohm @ 4.5V.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the SI1965DH-T1-GE3, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
