Name: CSD87381P
Brand: Texas Instruments
SKU: CSD87381P
Price: 0.97000 USD
Availability: InStock

new-10%

CSD87381P

Manufacturer part number:CSD87381P

Manufacturer:Texas Instruments

Description:MOSFET Sync Buck NexFET Pwr Block II

Case Package:SOT-23

Datasheet:CSD87381P Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Lifecycle Status	ACTIVE (Last Updated: 3 days ago)
Contact Plating	Gold
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	5-LGA
Number of Pins	5
Operating Temperature	-55°C~150°C TJ
Packaging	Tape & Reel (TR)
Series	NexFET™
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	5
ECCN Code	EAR99
Max Power Dissipation	4W
Terminal Position	UNSPECIFIED
Terminal Form	UNSPECIFIED
Peak Reflow Temperature (Cel)	260
Number of Functions	1
[email protected] Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	CSD87381
Number of Outputs	1
Max Output Current	40A
Input Voltage-Nom	12V
Analog IC - Other Type	SWITCHING REGULATOR
Element Configuration	Single
Power Dissipation	4W
FET Type	2 N-Channel (Half Bridge)
Input Voltage (Max)	24V
Rds On (Max) @ Id, Vgs	16.3m Ω @ 8A, 8V
Vgs(th) (Max) @ Id	1.9V @ 250μA
Output Current per Channel	15A
Control Technique	PULSE WIDTH MODULATION
Input Capacitance (Ciss) (Max) @ Vds	564pF @ 15V
Gate Charge (Qg) (Max) @ Vgs	5nC @ 4.5V
Rise Time	16.3ns
Drain to Source Voltage (Vdss)	30V
Fall Time (Typ)	2.9 ns
Turn-Off Delay Time	16.8 ns
Switcher Configuration	BUCK
Continuous Drain Current (ID)	15A
Gate to Source Voltage (Vgs)	8V
Drain to Source Breakdown Voltage	30V
FET Feature	Logic Level Gate
Height	480μm
Length	3mm
Width	2.5mm
Thickness	400μm
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

CSD87381P Product Details

The Texas Instruments CSD87381P Transistors - FETs, MOSFETs - Arrays is a high-performance power block designed to provide efficient power conversion in a wide range of applications. This device features a MOSFET Sync Buck NexFET Pwr Block II, which is capable of delivering up to 30A of continuous current and up to 60A of peak current. The device also features a low on-resistance of 0.0045Ω, allowing for high efficiency power conversion. Additionally, the device is designed to operate over a wide temperature range of -40°C to +125°C, making it suitable for a variety of applications. The CSD87381P is an ideal solution for applications requiring high-efficiency power conversion.
