Name: MKP386M540070JT2
Brand: Vishay BC Components
SKU: MKP386M540070JT2
Price: 21.93000 USD
Availability: InStock

new

MKP386M540070JT2

Manufacturer part number:MKP386M540070JT2

Manufacturer:Vishay BC Components

Description:MKP386M 4μF Film Capacitor ±5% Rectangular Box Screw Terminals 700V-DC 420V-AC Polypropylene (PP), Metallized Chassis Mount

Case Package:SOT-23

Datasheet:MKP386M540070JT2 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Mount	Chassis Mount
Mounting Type	Chassis Mount
Package / Case	Rectangular Box
Terminal Shape	LUG
Dielectric Material	Polypropylene (PP), Metallized
Operating Temperature	-55°C~105°C
Packaging	Bulk
Series	MKP386M
Size / Dimension	1.732Lx1.181W 44.00mmx30.00mm
Tolerance	±5%
JESD-609 Code	e3
Feature	Low ESR
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	Screw Terminals
ECCN Code	EAR99
Terminal Finish	Tin (Sn)
Applications	Snubber
HTS Code	8532.25.00.80
Capacitance	4μF
Voltage - Rated DC	700V
Reach Compliance Code	unknown
Reference Standard	IEC60384-17
Voltage - Rated AC	420V
Lead Pitch	6.1976mm
Capacitor Type	FILM CAPACITOR
ESR (Equivalent Series Resistance)	4.5mOhm
Lead Spacing	0.244 6.20mm
Height Seated (Max)	1.811 46.00mm
Length	44mm
Width	30mm
RoHS Status	ROHS3 Compliant

MKP386M540070JT2 Product Details

MKP386M540070JT2 Overview

As a result, the device has 4.5mOhm equivalent series resistance (ESR).Electrical devices with 0.244 6.20mm lead spacing are used in this application.-55°C~105°C is the maximum temperature at which the device can operate.
