650861-4

new-10%

650861-4

Manufacturer part number:650861-4

Manufacturer:TE Connectivity AMP Connectors

Description:650861-4 datasheet pdf and Backplane Connectors - DIN 41612 product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:650861-4 Datasheet

RoHs Status:non-compliant

Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 3 days ago)
Factory Lead Time	26 Weeks
Contact Material	Bronze
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyester
Material - Insulation	Polyester, Glass Filled
Operating Temperature	-55°C~125°C
Packaging	Bulk
Series	Eurocard
Published	1997
Pbfree Code	no
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Receptacle, Female Sockets
Number of Rows	2
Gender	Female
HTS Code	8536.69.40.40
MIL Conformance	NO
DIN Conformance	YES
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.100 2.54mm
Total Number of Contacts	64
Orientation	Straight
Style	B
Number of Positions Loaded	All
Reference Standard	UL
Contact Finish	Gold
Reliability	COMMERCIAL
Number Of PCB Rows	2
Lead Pitch	2.54mm
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.317 inch
UL Flammability Code	94V-0
Housing Color	Grey
Body Depth	0.453 inch
Rated Current (Signal)	1.5A
Contact Resistance	15mOhm
Insulation Resistance	1000000000000Ohm
Row Spacing	2.54 mm
Max Voltage Rating (AC)	250V
Polarization Key	POLARIZED HOUSING
Dielectric Withstanding Voltage	1000VAC V
Max Voltage Rating (DC)	250V
Sealable	No
Insulator Color	GRAY
Number of Power Positions	64
Number of Columns	32
Termination Post Length	3.3mm
Name of Rows Loaded	A,B
Length	94mm
Material Flammability Rating	UL94 V-0
RoHS Status	Non-RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Contains Lead
