Name: 2-1658016-3
Brand: TE Connectivity AMP Connectors
SKU: 2-1658016-3
Price: 47.42000 USD
Availability: InStock

new

2-1658016-3

Manufacturer part number:2-1658016-3

Manufacturer:TE Connectivity AMP Connectors

Description:Plug, Outer Shroud ContactsTray2 Rows0.031 0.80mmSurface Mount120 PositionsMICTORGoldSMD/SMTBronze

Case Package:SOT-23

Datasheet:2-1658016-3 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	11 Weeks
Lifecycle Status	ACTIVE (Last Updated: 5 days ago)
Contact Material	Bronze
Contact Plating	Gold, Nickel
Mounting Type	Surface Mount
Contact Shape	Square
Housing Material	Polymer
Mounting Option 1	LOCKING
PCB Mount Alignment	With
Packaging	Tray
Published	2007
Series	MICTOR
Feature	Board Guide, Ground Bus (Plane)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	SMD/SMT
Connector Type	Plug, Outer Shroud Contacts
Number of Positions	120
Max Operating Temperature	257°C
Min Operating Temperature	-85°C
Number of Rows	2
Subcategory	Headers and Edge Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.031 0.80mm
Total Number of Contacts	120
Orientation	Vertical
Number of Conductors	ONE
Contact Finish	Gold
Reliability	COMMERCIAL
Number Of PCB Rows	2
PCB Contact Pattern	RECTANGULAR
Contact Gender	MALE
Housing Color	Black
Body Depth	0.6 inch
Operating Supply Voltage	125V
Insulation Resistance	5GOhm
Row Spacing	4.02 mm
ELV	Compliant
Polarization Key	POLARIZED HOUSING
Dielectric Withstanding Voltage	675VAC V
Impedance	50Ohm
Durability	100 Cycles
Contact Pattern	RECTANGULAR
Sealable	No
Contact Current Rating	1.25A
Mating Alignment	Without
Height	15.34922mm
Contact Finish Thickness	10.0μin 0.25μm
Plating Thickness	250 nm
Contact Finish Thickness - Mating	249.9995 nm
Height Above Board	0.600 15.24mm
Stack Height	16mm
RoHS Status	RoHS Compliant

2-1658016-3 Product Details

2-1658016-3 Overview

Packaging is in the form of Plug, Outer Shroud Contacts.An orange Tray case is used to package the product.This device has a Surface Mount mounting type.Specifically, it is one of the products in the MICTOR Series.In operation, Board Guide, Ground Bus (Plane) can be maintained as long as Board Guide, Ground Bus (Plane) is unchanged.If the temperature is below 257°C, it's best to use it.-85°C is the minimum temperature for this device.This device can be used with a 125V supply, as it is designed for that operation.
