Name: LSS-120-01-L-DV-A-K
Brand: Samtec Inc.
SKU: LSS-120-01-L-DV-A-K
Price: 6.01000 USD
Availability: InStock

new-10%

LSS-120-01-L-DV-A-K

Manufacturer part number:LSS-120-01-L-DV-A-K

Manufacturer:Samtec Inc.

Description:Self Mating, Non-Gendered Tube 2 Rows 0.025 0.64mm Surface Mount 40 Positions Razor Beam™ LSS Gold Solder Bronze

Case Package:SOT-23

Datasheet:LSS-120-01-L-DV-A-K Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	Bronze
Mounting Type	Surface Mount
Housing Material	Polymer
Mounting Option 1	LOCKING
Packaging	Tube
Published	2016
Series	Razor Beam™ LSS
JESD-609 Code	e3
Feature	Board Guide, Pick and Place
Part Status	Active
Termination	Solder
ECCN Code	EAR99
Connector Type	Self Mating, Non-Gendered
Number of Positions	40
Max Operating Temperature	125°C
Min Operating Temperature	-55°C
Number of Rows	2
Gender	Hermaphroditic
Subcategory	Headers and Edge Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.025 0.64mm
Total Number of Contacts	40
Orientation	Straight
Depth	4.14mm
Number of Conductors	ONE
Reference Standard	UL
Contact Finish	Gold
Reliability	COMMERCIAL
Number Of PCB Rows	2
PCB Contact Pattern	RECTANGULAR
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Body Breadth	0.163 inch
Housing Color	Black
Contact Pattern	RECTANGULAR
Length	17.45mm
Contact Finish Thickness	10.0μin 0.25μm
Plating Thickness	10μin
Height Above Board	0.169 4.30mm
Stack Height (Mating)	6mm 7mm 9mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

LSS-120-01-L-DV-A-K Product Details

LSS-120-01-L-DV-A-K Overview

Currently, it is packaged in Self Mating, Non-Gendered.A Tube case is used to package the product.The mounting type of the device is Surface Mount.A product of the Razor Beam™ LSS Series, it belongs to the range of products of that series.The operating system can be configured to maintain the value of Board Guide, Pick and Place when it operates.A temperature below 125°C is best for using it.The device must run at -55°C degrees.
