Name: CLM-115-02-F-D-BE-TR
Brand: Samtec Inc.
SKU: CLM-115-02-F-D-BE-TR
Availability: InStock

new-10%

CLM-115-02-F-D-BE-TR

Manufacturer part number:CLM-115-02-F-D-BE-TR

Manufacturer:Samtec Inc.

Description:2 Rows Receptacle, Bottom Entry Solder Phosphor Bronze Surface Mount Tape & Reel (TR) Gold Liquid Crystal Polymer (LCP) 30 Positions Female Socket

Case Package:SOT-23

Datasheet:CLM-115-02-F-D-BE-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	Phosphor Bronze
Mounting Type	Surface Mount
Contact Shape	Square
Insulation Material	Liquid Crystal Polymer (LCP)
Operating Temperature	-55°C~125°C
Packaging	Tape & Reel (TR)
Series	CLM
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Receptacle, Bottom Entry
Number of Positions	30
Number of Rows	2
Additional Feature	BOTTOM ENTRY, TAPE&REEL PKG
HTS Code	8536.69.40.40
Fastening Type	Push-Pull
Subcategory	Headers and Edge Type Connectors
Contact Finish - Mating	Gold
Contact Type	Female Socket
Current Rating (Amps)	2.8A per Contact
Total Number of Contacts	30
Terminal Pitch	0.9906mm
Insulation Height	0.084 2.14mm
Style	Board to Board
Number of Positions Loaded	All
Pitch - Mating	0.039 1.00mm
Insulation Color	Black
Number of Conductors	ONE
Reference Standard	UL
Reliability	COMMERCIAL
Body Length or Diameter	0.608 inch
Row Spacing - Mating	0.039 (1.00mm)
Number Of PCB Rows	2
Contact Finish - Post	Tin
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.1 inch
Body Depth	0.084 inch
Contact Resistance	15mOhm
Mating Contact Pitch	0.039 inch
PCB Contact Row Spacing	3.175 mm
Durability	100 Cycles
Insertion Force-Max	.417 N
Plating Thickness	FLASH inch
Contact Finish Thickness - Mating	3.00μin 0.076μm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

CLM-115-02-F-D-BE-TR Product Details

CLM-115-02-F-D-BE-TR Overview

Packaging for this item is Receptacle, Bottom Entry.There is a mounting type of Surface Mount for this device.It is necessary to use a Tape & Reel (TR) case for packaging the product.This product is part of the CLM Series.Moreover, there are a number of other features, including BOTTOM ENTRY, TAPE&REEL PKG, to name just a few.In this case, the device operates at -55°C~125°C Operating Temperature.
