Name: BTH-090-01-L-D-A-K
Brand: Samtec Inc.
SKU: BTH-090-01-L-D-A-K
Price: 13.16000 USD
Availability: InStock

new

BTH-090-01-L-D-A-K

Manufacturer part number:BTH-090-01-L-D-A-K

Manufacturer:Samtec Inc.

Description:BTH-090-01-L-D-A-K datasheet pdf and Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) product details from Samtec Inc. stock available on our website

Case Package:SOT-23

Datasheet:BTH-090-01-L-D-A-K Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	Bronze
Mounting Type	Surface Mount
Insulation Material	LIQUID CRYSTAL POLYMER (LCP)
Board Mounting Option	POSITIONING PIN
Packaging	Tube
Published	2015
Series	BTH
JESD-609 Code	e3
Feature	Board Guide, Pick and Place
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header, Outer Shroud Contacts
Number of Positions	180
Number of Rows	2
Gender	Male
Additional Feature	PICK & PLACE PAD
Subcategory	Headers and Edge Type Connectors
Pitch	0.020 0.50mm
Total Number of Contacts	180
Number of Conductors	ONE
Reference Standard	UL
Contact Finish	Gold
Reliability	COMMERCIAL
Body Length or Diameter	1.969 inch
Number Of PCB Rows	2
PCB Contact Pattern	RECTANGULAR
Operating Temperature (Min)	-65°C
Body Depth	0.168 inch
Contact Style	BELLOWED TYPE
Body/Shell Style	RECEPTACLE
Polarization Key	POLARIZED HOUSING
PCB Contact Row Spacing	6.096 mm
Contact Pattern	RECTANGULAR
Contact Finish Thickness	10.0μin 0.25μm
Plating Thickness	10μin
Height Above Board	0.168 4.27mm
Stack Height (Mating)	5mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

BTH-090-01-L-D-A-K Product Details

BTH-090-01-L-D-A-K Overview

The packaging contains Header, Outer Shroud Contacts.Packaged in a Tube case.Surface Mount is the mounting type.The product belongs to the BTH Series.If Board Guide, Pick and Place is maintained, it will operate.Other features include PICK & PLACE PAD, to name just a few.
