803-83-020-10-005101

  • 803-83-020-10-005101 - 2 RowsSocketSolderBeryllium CopperThrough HoleBulkGoldPolycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled20 PositionsFemale Socket
  • 803-83-020-10-005101 - 2 RowsSocketSolderBeryllium CopperThrough HoleBulkGoldPolycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled20 PositionsFemale Socket

803-83-020-10-005101

803-83-020-10-005101

Preci-Dip

2 RowsSocketSolderBeryllium CopperThrough HoleBulkGoldPolycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled20 PositionsFemale Socket

SOT-23

803-83-020-10-005101 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 10 Weeks
Contact MaterialBeryllium Copper
Mount Through Hole
Mounting Type Through Hole
Contact Shape Circular
Insulation Material Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Operating Temperature-55°C~125°C
PackagingBulk
Published 2012
Series 803
JESD-609 Code e3
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Socket
Number of Positions 20
Number of Rows 2
HTS Code8536.69.40.40
Fastening TypePush-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
Contact Type Female Socket
Current Rating (Amps) 3A
Insulation Height 0.335 8.51mm
Style Board to Board
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 1 inch
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.118 3.00mm
Number Of PCB Rows 2
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Body Depth 0.335 inch
Contact Resistance 10mOhm
Insulation Resistance10000000000Ohm
Mating Contact Pitch 0.1 inch
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 1400VAC V
Durability 500 Cycles
Plating Thickness 30μin
Contact Finish Thickness - Mating 29.5μin 0.75μm
Length - Termination 0.118 inch
Material Flammability Rating UL94 V-0
RoHS StatusROHS3 Compliant
In-Stock:2937 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$4.563395$4.563395
10$4.305090$43.0509
100$4.061405$406.1405
500$3.831514$1915.757
1000$3.614636$3614.636

803-83-020-10-005101 Product Details

803-83-020-10-005101 Overview


A Socket package is included with it.Mounting type Through Hole is assigned to the device.Packaging the product involves using a Bulk case.This product is in the 803 Series.The part is mounted by Through Hole.There is no operating temperature for the device.

803-83-020-10-005101 Features


803 series

803-83-020-10-005101 Applications


There are a lot of Preci-Dip 803-83-020-10-005101 Rectangular Connectors applications.

  • Communication
  • Instrumentation
  • Measuring & Control Technology
  • Data Technology
  • Industrial Automation
  • Datacom
  • Medical technology
  • Transportation
  • Automotive Electronics
  • Military Technology
