Name: 1788664
Brand: Phoenix Contact
SKU: 1788664
Price: 30.51000 USD
Availability: InStock

new

1788664

Manufacturer part number:1788664

Manufacturer:Phoenix Contact

Description:Bulk 0.200 5.08mm Green 1 Levels Board Mount Receptacle, Male Pins COMBICON MVSTBU Polyamide (PA), Nylon

Case Package:SOT-23

Datasheet:1788664 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Plating	Tin
Mount	Cable, Panel
Mounting Type	Board Mount
Material	Polyamide
Housing Material	Polyamide (PA), Nylon
Weight	206.999996g
Packaging	Bulk
Series	COMBICON MVSTBU
Published	2010
Feature	Mounting Flange
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Plug
Type	Receptacle, Male Pins
Number of Positions	15
Color	Green
Number of Rows	1
Gender	Female
Voltage - Rated	320V
Additional Feature	PA, 94V-2
HTS Code	8536.69.40.40
Pitch	0.200 5.08mm
Orientation	Straight
Depth	20.4mm
Insulation Height	0.681 17.30mm
Reach Compliance Code	unknown
Current Rating	12A
Termination Style	Screw
Number of Contacts	15
Voltage	300V
Max Current Rating	12A
Number of Levels	1
Current	10A
Wire Gauge (Max)	12 AWG
Wire Gauge (Min)	24 AWG
Number of Decks	1
Wire Gauge or Range - AWG	12-30 AWG
Voltage - IEC	630V
Torque - Screw	0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways	15
Safety Approval	UL
Wire Gauge or Range - mm²	0.2-2.5mm2
Wire Strip Length	7mm
Screw Size	M3
Wire Cross Section	2.5 mm2
Height	20.4mm
Length	87.52mm
Width	17.3mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1788664 Product Details

1788664 Overview

It comes in Plug packaging.The device's mounting type is Board Mount.In order to package the product, a Bulk case is used.It belongs to the COMBICON MVSTBU Series of products.In addition, there are other features such as PA, 94V-2, to mention only a few.Its Mounting Flange feature renders it more powerful in many ways.The part is mounted by Cable, Panel.This part shares lots of benefits with other Receptacle, Male Pins products.
