Name: 1776524
Brand: Phoenix Contact
SKU: 1776524
Price: 4.46000 USD
Availability: InStock

new-10%

1776524

Manufacturer part number:1776524

Manufacturer:Phoenix Contact

Description:1776524 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1776524 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polybutylene Terephthalate (PBT)
Weight	152.999995g
Packaging	Bulk
Published	2003
Series	COMBICON MSTB
Feature	Mating and Mounting Flange
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Plug
Type	Header, Male Pins, Shrouded (4 Side)
Color	Green
Number of Rows	1
Voltage - Rated	250V
Pitch	0.200 5.08mm
Orientation	Right Angle
Depth	12mm
Insulation Height	0.339 8.61mm
Current Rating	12A
Termination Style	Solder
Voltage	300V
Contact Tail Length	0.138 3.50mm
Max Current Rating	12A
Number of Levels	1
Current	12A
Number of Decks	1
Current - UL	15A
Voltage - IEC	400V
Number of Ways	4
Safety Approval	CB; CSA; CUL; GOST; UL; VDE
Header Orientation	90°, Right Angle
Number of Positions Per Level	4
Fastening Method	CONNECTOR
Height	12.1mm
Length	30.48mm
Width	30.48mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1776524 Product Details

1776524 Overview

You'll get Plug packages.A Through Hole mounting type is specified for the device.To package the product, we use a Bulk case.Product number COMBICON MSTB belongs to the COMBICON MSTB Series.As a result of its Mating and Mounting Flange feature, it possesses a great deal of power.Part Through Hole is mounted to the part.As with other Header, Male Pins, Shrouded (4 Side) products, this part also offers a wide range of benefits.
