Name: 1729092
Brand: Phoenix Contact
SKU: 1729092
Price: 5.87000 USD
Availability: InStock

new-10%

1729092

Manufacturer part number:1729092

Manufacturer:Phoenix Contact

Description:0.197 5.00mm Green Bulk Polyamide (PA), Nylon Through Hole Horizontal with Board Screw - Rising Cage Clamp 1 Levels 14-30 AWG COMBICON MKDSN

Case Package:SOT-23

Datasheet:1729092 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Contact Material	Tin
Mount	Through Hole
Mounting Type	Through Hole
Insulation Material	Nylon
Material	Polyamide
Housing Material	Polyamide (PA), Nylon
Weight	9.199987g
Packaging	Bulk
Series	COMBICON MKDSN
Published	2008
Feature	Interlocking (Side)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Screw
Color	Green
Number of Rows	1
Gender	Male
Voltage - Rated	400V
Additional Feature	PA, 94V-0
HTS Code	8536.90.40.00
Pitch	0.197 5.00mm
Orientation	Straight
Depth	8.1mm
Current Rating	13.5A
Approval Agency	CB, CSA, UL, cULus
Number of Contacts	10
Wire Gauge	14-30 AWG
Voltage	300V
Max Supply Voltage	250V
Max Current Rating	13.5A
Number of Levels	1
Current	10A
Wire Gauge (Max)	26 AWG
Wire Gauge (Min)	14 AWG
Number of Decks	1
Terminal and Terminal Block Type	BARRIER STRIP TERMINAL BLOCK
Torque - Screw	0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways	10
Safety Approval	UL
Mating Orientation	Horizontal with Board
Wire Termination	Screw - Rising Cage Clamp
Screw Thread	M3
Stripping Length	6mm
Height	13.5mm
Length	8.1mm
Width	50mm
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1729092 Product Details

1729092 Overview

It comes in Screw packaging.The device's mounting type is Through Hole.In order to package the product, a Bulk case is used.It belongs to the COMBICON MKDSN Series of products.In addition, there are other features such as PA, 94V-0, to mention only a few.Its Interlocking (Side) feature renders it more powerful in many ways.The part is mounted by Through Hole.The supply voltage of this chip should not exceed 250V.
