Name: 1984659
Brand: Phoenix Contact
SKU: 1984659
Price: 1.54000 USD
Availability: InStock

new-10%

1984659

Manufacturer part number:1984659

Manufacturer:Phoenix Contact

Description:0.138 3.50mm Green Bulk Polyamide (PA), Nylon Through Hole Horizontal with Board Screw 1 Levels 16-26 AWG COMBICON PT

Case Package:SOT-23

Datasheet:1984659 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Material	Tin
Mount	Through Hole
Mounting Type	Through Hole
Insulation Material	Nylon
Material	Polyamide
Housing Material	Polyamide (PA), Nylon
Weight	2.829991g
Packaging	Bulk
Series	COMBICON PT
Published	2005
Feature	Interlocking (Side)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Color	Green
Number of Rows	1
Gender	Male
Voltage - Rated	160V
Pitch	0.138 3.50mm
Orientation	Straight
Depth	7.6mm
Current Rating	17.5A
Approval Agency	UL
Number of Contacts	6
Wire Gauge	16-26 AWG
Voltage	300V
Max Supply Voltage	160V
Max Current Rating	17.5A
Number of Levels	1
Current	10A
Wire Gauge (Max)	26 AWG
Wire Gauge (Min)	26 AWG
Number of Decks	1
Terminal and Terminal Block Type	BARRIER STRIP TERMINAL BLOCK
Torque - Screw	0.22-0.25 Nm (1.9-2.2 Lb-In)
Number of Ways	6
Safety Approval	UL
Mating Orientation	Horizontal with Board
Wire Termination	Screw
Screw Thread	M2
Stripping Length	5mm
Height	9mm
Length	21mm
Width	7.6mm
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1984659 Product Details

1984659 Overview

The device's mounting type is Through Hole.In order to package the product, a Bulk case is used.It belongs to the COMBICON PT Series of products.Its Interlocking (Side) feature renders it more powerful in many ways.The part is mounted by Through Hole.The supply voltage of this chip should not exceed 160V.
