1717974

1717974

1717974

Phoenix Contact

1717974 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

SOT-23

1717974 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 9 Weeks
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA), Nylon
Weight 907.18474g
PackagingBulk
Published 2011
Series COMBICON QC
Feature Retention Latches (Non-Wire Side)
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
ECCN Code EAR99
Connector Type IDC, IDT
Type Plug, Female Sockets
Color Green
Number of Rows 1
Voltage - Rated 500V
Additional FeaturePA, 94V-0
Pitch 0.197 5.00mm
Insulation Height 0.772 19.60mm
Current Rating12A
Termination Style Screwless - IDC
Approval Agency cULus
Voltage 300V
Number of Levels 1
Current 10A
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 16 AWG
Contact Mating Finish Tin
Number of Decks 1
Wire Gauge or Range - AWG 16-24 AWG
Voltage - IEC 1kV
Number of Ways 3
Safety Approval UL
Plug Wire Entry 180°
Wire Gauge or Range - mm² 0.2-1.5mm2
Current - IEC 12A
Number of Positions Per Level 3
Material Flammability Rating UL94 V-0
RoHS StatusRoHS Compliant
Flammability Rating UL94 V-0
In-Stock:2306 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$2.741328$2.741328
10$2.586159$25.86159
100$2.439772$243.9772
500$2.301671$1150.8355
1000$2.171388$2171.388

1717974 Product Details

1717974 Overview


It comes in IDC, IDT packaging.It's mounted Free Hanging (In-Line).A Bulk case is used to package the product.Product number COMBICON QC belongs to the COMBICON QC Series.Additionally, there are other features such as PA, 94V-0.Many aspects of its Retention Latches (Non-Wire Side) feature increase its effectiveness.You've got Free Hanging mounted on the part.Other Plug, Female Sockets products benefit from this part as well.

1717974 Features


COMBICON QC series

1717974 Applications


There are a lot of Phoenix Contact 1717974 Terminal Blocks applications.

  • Communication
  • Energy efficient lighting (LED)
  • Variable speed/frequency drivers
  • Military Technology
  • Data Technology
  • Anywhere power is distributed
  • Blowers
  • Datacom
  • Electrical substations
  • Instrumentation
