NL17SZ32P5T5G Overview
The part is convenient to ship overseas because it is packed in a SOT-953. The advanced packaging method Tape & Reel (TR) provides high reliability. A OR Gate logic principle governs its operation. Voltage 1.65V~5.5V is needed to ensure the part's full functionality. Operational temperature extended around -55°C~125°C. Mounted in Surface Mount. Output current is 32mA 32mA in the high and low states. 17SZ is the series it belongs to. The total number of terminations is 5. There are 1 functions that significantly improve the user experience. As part of LVC/LCX/Z, this chip is used. Try searching with 17SZ32 to find device variants. A total of 5 pins are injected into the body of the part. Logic devices with Surface Mount mounting are widely used in many applications. Datasheets for functions of 5 pins are available. Inputs are limited to 2. Quiescent parts have 1μA current flowing through them. The device consists of 1 circuits.
NL17SZ32P5T5G Features
OR Gate Logic Type
Operating Temperature: -55°C~125°C
LVC/LCX/Z Family
Quiescent Current: 1μA
NL17SZ32P5T5G Applications
There are a lot of ON Semiconductor
NL17SZ32P5T5G Gates and Inverters applications.
- Electric grinding wheel
- Electrical tools
- Sewing machine
- DVD
- VCD
- Computer
- Television
- Washing machine
- Range hood
- Refrigerator
