Name: NCP12400BAHAB0DR2G
Brand: ON Semiconductor
SKU: NCP12400BAHAB0DR2G
Availability: InStock

new-10%

NCP12400BAHAB0DR2G

Manufacturer part number:NCP12400BAHAB0DR2G

Manufacturer:ON Semiconductor

Description:7 Terminations10.5V~28V AC to DC power converter65kHz

Case Package:SOT-23

Datasheet:NCP12400BAHAB0DR2G Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Lifecycle Status	ACTIVE (Last Updated: 1 day ago)
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154, 3.90mm Width), 7 Leads
Surface Mount	YES
Operating Temperature	-40°C~125°C TJ
Packaging	Tape & Reel (TR)
Published	2009
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	7
Terminal Finish	Tin (Sn)
Terminal Position	DUAL
Terminal Form	GULL WING
Number of Functions	1
Terminal Pitch	1.27mm
JESD-30 Code	R-PDSO-G7
Input Voltage-Nom	11V
Analog IC - Other Type	SWITCHING CONTROLLER
Voltage - Supply (Vcc/Vdd)	10.5V~28V
Input Voltage (Min)	9.3V
Topology	Flyback
Control Mode	CURRENT-MODE
Frequency - Switching	65kHz
Control Technique	PULSE WIDTH MODULATION
Internal Switch(s)	No
Fault Protection	Over Load, Over Power, Over Temperature, Over Voltage
Duty Cycle	80%
Output Isolation	Isolated
Voltage - Start Up	12V
Height Seated (Max)	1.75mm
Length	4.9mm
Width	3.9mm
RoHS Status	ROHS3 Compliant

NCP12400BAHAB0DR2G Product Details

NCP12400BAHAB0DR2G Overview

There is a ac to dc converter embedded in package 8-SOIC (0.154, 3.90mm Width), 7 Leads .You can get it in AC/DC power converter Tape & Reel (TR) .In this case, the AC/DC converter is mounted in the way of Surface Mount .This ac dc converter should be operated at a temperature of -40°C~125°C TJ °C so that it can deliver its performance.An analog IC of type SWITCHING CONTROLLER is employed in this AC DC converter.The switching frequency reaches 65kHz .Within the range of 10.5V~28V supply voltage (Vcc/Vdd), it can be used.In total, there are 7 terminations.
