Name: PIC18F45K22-I/P
Brand: Microchip Technology
SKU: PIC18F45K22-I/P
Price: 4.15000 USD
Availability: InStock

new-10%

PIC18F45K22-I/P

Manufacturer part number:PIC18F45K22-I/P

Manufacturer:Microchip Technology

Description:32KB 16K x 16 FLASH PIC 8-Bit Microcontroller PIC® XLP™ 18K Series PIC18F45K22 40 Pin 64 MHz 5V 40-DIP (0.600, 15.24mm)

Case Package:SOT-23

Datasheet:PIC18F45K22-I/P Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Lifecycle Status	Production (Last Updated: 2 years ago)
Mounting Type	Through Hole
Package / Case	40-DIP (0.600, 15.24mm)
Surface Mount	NO
Number of Pins	40
Supplier Device Package	40-PDIP
Mounting Style	Through Hole
Interfaces	I2C/SPI/USART
Number of I/Os	35
RoHS	Compliant
Data Converters	A/D 30x10b
Package	Tube
Base Product Number	PIC18F45
Mfr	Microchip Technology
Product Status	Active
Family Name	PIC18F
Instruction Set Architecture	RISC
Dimensions	2.095 x 0.58 x 0.195in
Typical Operating Supply Voltage	2.3 → 5.5 V
Package Type	PDIP
Maximum Operating Temperature	+85 °C
Minimum Operating Temperature	-40 °C
MSL	MSL 1 - Unlimited
Qualification	AEC-Q100
Interface Type	EUSART, I2C, SPI
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
Tradename	PIC
Operating Temperature	-40°C~85°C TA
Packaging	Tube
Series	PIC® XLP™ 18K
Published	2006
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	Not Applicable
Number of Terminations	40
ECCN Code	3A991.A.2
Terminal Finish	Matte Tin (Sn) - annealed
Max Operating Temperature	85 °C
Min Operating Temperature	-40 °C
Additional Feature	ALSO OPERATES 2.3 V MINIMUM SUPPLY AT 20 MHZ
HTS Code	8542.31.00.01
Max Power Dissipation	1 W
Terminal Position	DUAL
Supply Voltage	5V
Terminal Pitch	2.54mm
Frequency	64 MHz
Base Part Number	PIC18F45K22
Pin Count	40
JESD-30 Code	R-PDIP-T40
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	2/5V
Supply Voltage-Min (Vsup)	2.7V
Interface	I2C, SPI, UART, USART
Max Supply Voltage	5.5 V
Min Supply Voltage	1.8 V
Memory Size	32 kB
Oscillator Type	Internal
Number of I/O	35
Speed	64MHz
RAM Size	1.5K x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	2.3V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Number of Bits	8
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Clock Frequency	64MHz
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	32KB 16K x 16
Connectivity	I2C, SPI, UART/USART
Supply Current-Max	12mA
Bit Size	8
Data Converter	A/D 30x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8 b
PWM Channels	YES
DAC Channels	YES
Number of Timers/Counters	7
Address Bus Width	8 b
Product Type	8-bit Microcontrollers - MCU
ROM (words)	16384
Core Architecture	PIC
EEPROM Size	256 x 8
On Chip Program ROM Width	16
CPU Family	PIC
Max Frequency	64 MHz
Number of A/D Converters	2
Number of Programmable I/O	36
Number of UART Channels	2
Number of ADC Channels	30
Number of PWM Channels	14
Number of I2C Channels	2
Number of SPI Channels	2
Number of Ethernet Channels	0
Product Category	8-bit Microcontrollers - MCU
Device Core	PIC
Length	51.7525mm
Width	15.24mm
Height	4.953 mm
RoHS Status	ROHS3 Compliant
REACH SVHC	No SVHC
Radiation Hardening	No
Lead Free	Lead Free

PIC18F45K22-I/P Product Details

PIC18F45K22-I/P Overview

The package has a 40-DIP (0.600, 15.24mm) shape. With 35 I/Os, it's pretty good. The Microcontroller's mounting type is Through Hole and this IC chip has the following features. As the name implies, this Microcontroller is based on the 8-Bit core. As far as its program memory type is concerned, it is FLASH. Temperatures within -40°C~85°C TA range are measured by this Microcontroller. The PIC® XLP™ 18K series is comprised of this electrical component. The electronic part has a program memory size of 32KB 16K x 16. There's a PIC Core Processor inside. The IC chip fits into the MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs category. There are 40 terminations on the IC chip. 8-bits are the size of the data that comes with MCU. A 5V volt supply is provided by the Microcontroller chip. In addition to that, MCU chip has NO DMA channels. Its memory size is 32 kB. It is possible to find alternatives to the base part number PIC18F45K22 by using the part number search tool. An effective performance can be achieved at a frequency of 64 MHz. There are a total of YES channels in the device. It is possible to access the 40 pins on the chip. In total, it has 7 timers and counters in it. A total of 40 pins are included in the package. There are several CPUs that are embedded in the device, including the the PIC CPU. The clock frequency is 64MHz. The equipment on this page features FLASH memory technology. This device features a PIC core architecture. As far as the programmability is concerned, it has 36 Programmable I/Os. As an example, there is a feature called ALSO OPERATES 2.3 V MINIMUM SUPPLY AT 20 MHZ to name only a few. As far as UART channels are concerned, it has 2. The ADC channels on this device total 30 in number. It has a set of 2 A/D converters on board the device. A chip with 8 bits has 8 bits in total. A total of 14 PWM channels are being used by the device. The part has been designed to incorporate 2 I2C channels.
