Name: K86X-CD-62S-BRJ
Brand: Kycon, Inc.
SKU: K86X-CD-62S-BRJ
Price: 13.34000 USD
Availability: InStock

new

K86X-CD-62S-BRJ

Manufacturer part number:K86X-CD-62S-BRJ

Manufacturer:Kycon, Inc.

Description:K86X-CD-62S-BRJ datasheet pdf and D-Sub Connectors product details from Kycon, Inc. stock available on our website

Case Package:SOT-23

Datasheet:K86X-CD-62S-BRJ Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	20 Weeks
Contact Material	Brass
Mounting Type	Through Hole
Dielectric Material	Polybutylene Terephthalate (PBT), Glass Filled
Shell Material, Finish	Steel, Nickel Plated
Mounting Option 2	THREADED
Operating Temperature	-55°C~75°C
Packaging	Tray
Published	2011
Series	K86X
JESD-609 Code	e4
Feature	Board Lock
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Receptacle, Female Sockets
Number of Positions	62
Color	Black
Number of Rows	3
Voltage - Rated	30VAC
Subcategory	D Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Signal
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	1.5A
Total Number of Contacts	62
Terminal Pitch	2.286mm
Shell Finish	TIN
Reference Standard	UL
Contact Finish	Gold
Reliability	COMMERCIAL
Body Length or Diameter	2.729 inch
Number Of PCB Rows	3
PCB Contact Pattern	STAGGERED
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Body Breadth	0.494 inch
Empty Shell	NO
Insulation Resistance	1000000000Ohm
Flange Feature	Board Side (4-40); Mating Side, Female Screwlock (4-40)
Mating Contact Pitch	0.09 inch
Dielectric Withstanding Voltage	1000VAC V
Connector Style	D-Sub, High Density
PCB Contact Row Spacing	1.9812 mm
Contact Form	Stamped
Shell Size, Connector Layout	4 DC C High Density
Contact Finish Thickness	Flash
Length - Termination	0.169 inch
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant

K86X-CD-62S-BRJ Product Details

K86X-CD-62S-BRJ Overview

You'll get Receptacle, Female Sockets packages.This device has a Through Hole mounting type.We use a Tray case to package the product.Product number K86X belongs to the K86X Series.There are a number of advantages to its Board Lock feature.Operating temperature is set to -55°C~75°C.
