Name: BSS123ATA
Brand: Diodes Incorporated
SKU: BSS123ATA
Availability: InStock

new-10%

BSS123ATA

Manufacturer part number:BSS123ATA

Manufacturer:Diodes Incorporated

Description:MOSFET N-Chnl 100V

Case Package:SOT-23

Datasheet:BSS123ATA Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	TO-236-3, SC-59, SOT-23-3
Number of Pins	3
Weight	7.994566mg
Transistor Element Material	SILICON
Operating Temperature	-55°C~150°C TJ
Packaging	Tape & Reel (TR)
Published	2012
JESD-609 Code	e3
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
Termination	SMD/SMT
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Voltage - Rated DC	100V
Technology	MOSFET (Metal Oxide)
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Reach Compliance Code	unknown
Current Rating	170mA
[email protected] Reflow Temperature-Max (s)	40
Qualification Status	Not Qualified
Number of Elements	1
Number of Channels	1
Voltage	100V
Power Dissipation-Max	360mW Ta
Element Configuration	Single
Current	15A
Operating Mode	ENHANCEMENT MODE
Power Dissipation	360mW
Turn On Delay Time	10 ns
FET Type	N-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	6 Ω @ 170mA, 10V
Vgs(th) (Max) @ Id	2V @ 1mA
Input Capacitance (Ciss) (Max) @ Vds	25pF @ 25V
Current - Continuous Drain (Id) @ 25°C	170mA Ta
Rise Time	10ns
Drive Voltage (Max Rds On,Min Rds On)	4.5V 10V
Vgs (Max)	±20V
Fall Time (Typ)	10 ns
Turn-Off Delay Time	15 ns
Continuous Drain Current (ID)	170mA
Gate to Source Voltage (Vgs)	20V
Drain to Source Breakdown Voltage	100V
Dual Supply Voltage	100V
Nominal Vgs	2 V
Height	1mm
Length	2.9mm
Width	1.3mm
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Lead Free	Contains Lead

About BSS123ATA

The BSS123ATA from Diodes Incorporated is a high-performance microcontroller designed for a wide range of embedded applications. This component features MOSFET N-Chnl 100V.
