Name: IRLR3715
Brand: Infineon Technologies
SKU: IRLR3715
Availability: InStock

new-10%

IRLR3715

Manufacturer part number:IRLR3715

Manufacturer:Infineon Technologies

Description:MOSFET N-CH 20V 54A DPAK

Case Package:SOT-23

Datasheet:IRLR3715 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	TO-252-3, DPak (2 Leads + Tab), SC-63
Surface Mount	YES
Transistor Element Material	SILICON
Operating Temperature	-55°C~175°C TJ
Packaging	Tube
Published	2001
Series	HEXFET®
JESD-609 Code	e3
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn) - with Nickel (Ni) barrier
Subcategory	FET General Purpose Power
Technology	MOSFET (Metal Oxide)
Terminal Position	SINGLE
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
[email protected] Reflow Temperature-Max (s)	30
JESD-30 Code	R-PSSO-G2
Qualification Status	Not Qualified
Number of Elements	1
Configuration	SINGLE WITH BUILT-IN DIODE
Power Dissipation-Max	3.8W Ta 71W Tc
Operating Mode	ENHANCEMENT MODE
Case Connection	DRAIN
FET Type	N-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	14m Ω @ 26A, 10V
Vgs(th) (Max) @ Id	3V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds	1060pF @ 10V
Current - Continuous Drain (Id) @ 25°C	54A Tc
Gate Charge (Qg) (Max) @ Vgs	17nC @ 4.5V
Drain to Source Voltage (Vdss)	20V
Drive Voltage (Max Rds On,Min Rds On)	4.5V 10V
Vgs (Max)	±20V
JEDEC-95 Code	TO-252AA
Drain Current-Max (Abs) (ID)	30A
Drain-source On Resistance-Max	0.011Ohm
Pulsed Drain Current-Max (IDM)	200A
DS Breakdown Voltage-Min	20V
Avalanche Energy Rating (Eas)	19 mJ
RoHS Status	Non-RoHS Compliant
