942C8W2K-F

  • 942C8W2K-F - 942C 2μF Film Capacitor ±10% Axial PC Pins 850V-DC 360V-AC Polypropylene (PP), Metallized Through Hole
  • 942C8W2K-F - 942C 2μF Film Capacitor ±10% Axial PC Pins 850V-DC 360V-AC Polypropylene (PP), Metallized Through Hole

942C8W2K-F

942C8W2K-F

Cornell Dubilier Electronics (CDE)

942C 2μF Film Capacitor ±10% Axial PC Pins 850V-DC 360V-AC Polypropylene (PP), Metallized Through Hole

SOT-23

942C8W2K-F Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 20 Weeks
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Dielectric MaterialPolypropylene (PP), Metallized
Operating Temperature-55°C~105°C
PackagingBulk
Published 2013
Series 942C
Size / Dimension 1.161Diax2.520L 29.50mmx64.00mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination PC Pins
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications High Pulse, DV/DT
Additional FeatureRATED AC VOLTAGE (V): 360
HTS Code8532.25.00.60
Capacitance 2μF
Voltage - Rated DC 850V
Voltage - Rated AC 360V
Capacitor Type FILM CAPACITOR
Dielectric PP
ESR (Equivalent Series Resistance) 3mOhm
Working Voltage 850V
Life (Hours) 2000 hours
Diameter 29.5mm
Length 64mm
REACH SVHC Unknown
RoHS StatusROHS3 Compliant
In-Stock:525 items

Pricing & Ordering

QuantityUnit PriceExt. Price
100$9.70500$970.5

942C8W2K-F Product Details

942C8W2K-F Overview


It has 3mOhm ESR (Equivalent Series Resistance).The device is capable of operating at the temperature of -55°C~105°C.

942C8W2K-F Features


3mOhm equivalent series resistance (ESR)

942C8W2K-F Applications


There are a lot of Cornell Dubilier Electronics (CDE) 942C8W2K-F applications of film capacitors.

  • Battery management system
  • Matching networks
  • Filtering
  • Lighting
  • RFI for automotive
  • Audio/video equipment
  • IGBT
  • Mobile communications
  • Snubbering
  • Test and measuring equipment
