Molex

0533071271 datasheet pdf and Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) product details from Molex stock available on our website

SOT-23

0533071271 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 10 Weeks
Contact MaterialPHOSPHOR BRONZE
Mounting Type Surface Mount
PackagingTape & Reel (TR)
Series SlimStack 53307
JESD-609 Code e3
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Header, Outer Shroud Contacts
Number of Positions 12
Number of Rows 2
Additional FeatureSHROUDED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.031 0.80mm
Total Number of Contacts 12
Contact Finish Tin
Contact Gender MALE
Contact Finish Thickness 120.0μin 3.05μm
Height Above Board 0.144 3.66mm
Stack Height (Mating) 4.5mm 5.5mm
RoHS StatusROHS3 Compliant
In-Stock:3382 items

Pricing & Ordering

QuantityUnit PriceExt. Price

0533071271 Product Details

0533071271 Overview


The packaging is Header, Outer Shroud Contacts.Packaging is performed using a Tape & Reel (TR) case.There is a mounting type of Surface Mount for this device.A product of the SlimStack 53307 Series, it belongs to the range of products of that series.Besides that, there's also SHROUDED, to name a few.

0533071271 Features


SlimStack 53307 series
Package / Case: Tape & Reel (TR)
Mounting Type:Surface Mount
Additional Feature: SHROUDED

0533071271 Applications


There are a lot of Molex 0533071271 Rectangular Connectors applications.

  • Measuring & Control Technology
  • Embedded systems
  • Communication
  • Datacom
  • Instrumentation
  • Transportation
  • Industrial Automation
  • Military Technology
  • Telecommunications
  • Medical technology
