Name: 767056-1
Brand: TE Connectivity AMP Connectors
SKU: 767056-1
Price: 16.48000 USD
Availability: InStock

new

767056-1

Manufacturer part number:767056-1

Manufacturer:TE Connectivity AMP Connectors

Description:767056-1 datasheet pdf and Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:767056-1 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	25 Weeks
Lifecycle Status	ACTIVE (Last Updated: 1 day ago)
Contact Plating	Gold
Mount	Surface Mount, Through Hole
Mounting Type	Surface Mount
Housing Material	Polymer
Underplate Material	Nickel
PCB Mount Alignment	With
Packaging	Tube
Published	2005
Series	MICTOR
Feature	Board Guide, Ground Bus (Plane)
Pbfree Code	no
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	SMD/SMT
Connector Type	Plug, Outer Shroud Contacts
Number of Positions	38
Max Operating Temperature	125°C
Min Operating Temperature	-55°C
Color	Black
Number of Rows	2
Subcategory	Headers and Edge Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.025 0.64mm
Total Number of Contacts	38
Orientation	Vertical
Depth	5.28mm
Number of Conductors	ONE
Reference Standard	UL
Contact Finish	Palladium-Nickel
Reliability	COMMERCIAL
Number Of PCB Rows	2
PCB Contact Pattern	RECTANGULAR
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Contact Gender	MALE
Operating Supply Voltage	30V
Rated Current (Signal)	1A
Contact Style	BELLOWED TYPE
Contact Resistance	10mOhm
Insulation Resistance	2MOhm
Row Spacing	5.79 mm
ELV	Compliant
Max Voltage Rating (AC)	30V
Polarization Key	POLARIZED HOUSING
Dielectric Withstanding Voltage	500VAC V
Durability	500 Cycles
Contact Pattern	RECTANGULAR
Sealable	No
Contact Current Rating	11.5A
Circuit Application	Signal
Data Rate	10 Gbps
Number of Power Positions	1
Number of Columns	19
Mating Alignment	Without
Differential Signaling	Yes
Height	6.5278mm
Length	25.4mm
Width	5.2832mm
Contact Finish Thickness	5.00μin 0.127μm
Plating Thickness	5μin
Contact Finish Thickness - Mating	120 nm
Height Above Board	0.251 6.38mm
Stack Height (Mating)	6.6mm 15.62mm
PCB Thickness	1.57mm
Stack Height	15.621mm
RoHS Status	Non-RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Contains Lead

767056-1 Product Details

767056-1 Overview

It comes in Plug, Outer Shroud Contacts packaging.Packaging the product involves using a Tube case.Surface Mount is the mounting type of the device.The product is a part of the MICTOR Series.It is possible to ensure that Board Guide, Ground Bus (Plane) remains constant during operation.You'll need a Surface Mount, Through Hole socket to mount it.Using it at a temperature below 125°C is ideal.Temperatures below -55°C are required for this device to operate.Since this device is suitable for use with a 30V supply, it can be used with it.
