ADF41020BCPZ Overview
Tray-method packaging is used for clock ICs. This clock generator is embedded in the 20-WFQFN Exposed Pad, CSP package. 20 terminations can be found in frequency generators. A voltage of 3V should be applied to this electronic frequency generator. CMOS, TTL is designed for clock generator's input. For full access to the electronic component's capabilities, 1 circuits are implemented. With the Surface Mount, it is easy to install this electric component on the panel. Clock generator ic works with 2.85V~3.15V. The temperature should be set at -40°C~85°C to ensure reliable performance. There are several logic levels in Clock logic that can be used with this clock generator. This is an electronic part that can be classified as a Clock/Frequency Synthesizer (RF) in this case. The clock-generating IC is a 20-bit device designed specifically for microprocessors. It is possible to find its related electronic parts by searching for the base part number ADF41020. PLL is designed with 20 pins. This clock generator can be classified as a kind of PLL or Frequency Synthesis Circuits in general. At frequencies of 18GHz, RF synthesizer achieves high efficiency. A supply current of 30mA is required to fully operate clock PLL. During this clock generator operation, a maximum current of 30mA is supplied. With this time clock generator, you get 2 inputs.
ADF41020BCPZ Features
Available in the 20-WFQFN Exposed Pad, CSP
Supply voltage of 3V
ADF41020BCPZ Applications
There are a lot of Analog Devices Inc. ADF41020BCPZ Clock Generators applications.
- Phase modulation cellular systems
- Medical equipment
- Line cards used in telephone exchange
- Cell phones
- GPS systems
- Mixed mode (analog and digital) applications
- Clock signals to the high-speed Digital RF circuits
- Threshold extension
- PMR (Professional Mobile Radio)
- Bluetooth receivers
