Name: 1969640000
Brand: Weidmüller
SKU: 1969640000
Price: 8.43000 USD
Availability: InStock

new-10%

1969640000

Manufacturer part number:1969640000

Manufacturer:Weidmüller

Description:1969640000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1969640000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mounting Type	Free Hanging (In-Line)
Insulation Material	Nylon
Housing Material	Polyamide (PA), Nylon, Glass Filled
Operating Temperature	-50°C~120°C
Packaging	Bulk
Series	Omnimate SC
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Type	Plug, Male Pins
Number of Positions	10
Color	Orange
Number of Rows	1
Voltage - Rated	300V
HTS Code	8536.69.40.40
Pitch	0.150 3.81mm
Ingress Protection	IP20
Insulation Height	0.437 11.10mm
Current Rating	10A
Termination Style	Screw - Clamping Yoke (Tension Sleeve)
Approval Agency	CSA, cURus
Number of Levels	1
Contact Mating Finish	Tin
Voltage - UL	300V
Number of Decks	1
Wire Gauge or Range - AWG	16-28 AWG
Voltage - IEC	320V
Torque - Screw	0.2-0.25 Nm (1.7-2.2 Lb-In)
Number of Ways	10
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-1.5mm2
Current - IEC	17.5A
Screw Size	M2
Stripping Length	7mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1969640000 Product Details

1969640000 Overview

Its mounting type is Free Hanging (In-Line).Packaging is performed using a Bulk case.A product of the Omnimate SC Series, it belongs to the range of products of that series.The device runs in -50°C~120°C Operating Temperature.This part shares lots of benefits with other Plug, Male Pins products.
