Name: 1776422001
Brand: Weidmüller
SKU: 1776422001
Price: 4.92000 USD
Availability: InStock

new-10%

1776422001

Manufacturer part number:1776422001

Manufacturer:Weidmüller

Description:1776422001 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1776422001 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Liquid Crystal Polymer (LCP), Glass Filled
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2008
Series	Omnimate SL
Feature	Mating Flange, Solder Retention
Pbfree Code	yes
Part Status	Active
Type	Header, Male Pins, Shrouded (4 Side)
Color	Black
Number of Rows	1
Voltage - Rated	300V
Additional Feature	PANEL MOUNTABLE
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.200 5.08mm
Total Number of Contacts	8
Depth	8.5mm
Insulation Height	0.472 12.00mm
Current Rating	15A
Termination Style	Solder
Approval Agency	CSA, UR
UL Flammability Code	94V-0
Voltage	300V
Contact Tail Length	0.059 1.50mm
Max Current Rating	15A
Number of Levels	1
Current	10A
Number of Poles	8
Contact Mating Finish	Tin
Current - UL	18.5A
Voltage - IEC	400V
Header Orientation	Vertical
Current - IEC	27.5A
Hole Diameter	1 mm
Length	50.44mm
Width	8.5mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Contains Lead

1776422001 Product Details

1776422001 Overview

A Through Hole mounting type is specified for the device.Packaging for the product is carried out via a Bulk case.The product is a part of the Omnimate SL Series.Other features include PANEL MOUNTABLE, to name just a few.Many aspects of its Mating Flange, Solder Retention feature increase its effectiveness.Through Hole represents the mounting point for the part.The device runs in -50°C~100°C Operating Temperature.There are a number of benefits that this part has in common with other Header, Male Pins, Shrouded (4 Side) products.
